General Specifications | |
Name | AMD Ryzen™ 5 8600G |
Family | Ryzen |
Series | Ryzen 8000 Series |
Form Factor | Desktops |
AMD PRO Technologies | No |
Commercial Use | Yes |
Regional Availability | Global |
Former Codename | Phoenix |
Architecture | Zen 4 |
# of CPU Cores | 6 |
Multithreading (SMT) | Yes |
# of Threads | 12 |
Max. Boost Clock | Up to 5GHz |
Base Clock | 4.3GHz |
L2 Cache | 6MB |
L3 Cache | 16MB |
Default TDP | 65W |
AMD Configurable TDP (cTDP) | 45-65W |
Processor Technology for CPU Cores | TSMC 4nm FinFET |
CPU Compute Die (CCD) Size | 178mm² |
Package Die Count | 1 |
AMD EXPO™ Memory Overclocking Technology | Yes |
Precision Boost Overdrive | Yes |
Curve Optimizer Voltage Offsets | Yes |
AMD Ryzen™ Master Support | Yes |
CPU Socket | AM5 |
CPU Boost Technology | Precision Boost 2 |
Instruction Set | x86-64 |
Supported Extensions | AES , AMD-V , AVX , AVX2 , AVX512 , FMA3 , MMX-plus , SHA , SSE , SSE2 , SSE3 , SSE4.1 , SSE4.2 , SSE4A , SSSE3 , x86-64 |
Max. Operating Temperature (Tjmax) | 95°C |
Launch Date | 1/31/2024 |
*OS Support | Windows 11 - 64-Bit Edition , Windows 10 - 64-Bit Edition , RHEL x86 64-Bit , Ubuntu x86 64-Bit |
Connectivity | |
Native USB 4 (40Gbps) Ports | 2 |
Native USB 3.2 Gen 2 (10Gbps) Ports | 2 |
Native USB 2.0 (480Mbps) Ports | 1 |
PCI Express® Version | PCIe® 4.0 |
Native PCIe® Lanes (Total/Usable) | 20 , 16 |
NVMe Support | Boot , RAID0 , RAID1 |
System Memory Type | DDR5 |
Memory Channels | 2 |
Max. Memory | 256 GB |
System Memory Subtype | UDIMM |
Max Memory Speed | 2x1R DDR5-5200 2x2R DDR5-5200 4x1R DDR5-3600 4x2R DDR5-3600 |
Graphics Capabilities | |
Graphics Model | AMD Radeon™ 760M |
Graphics Core Count | 8 |
Graphics Frequency | 2800 MHz |
DirectX® Version | 12 |
DisplayPort™ Version | 2.1 |
DisplayPort Extensions | Adaptive-Sync , HDR Metadata , UHBR10 |
DisplayPort Max Refresh Rates (SDR) | 7680x4320 @ 60Hz , 3840x2160 @ 240Hz , 3440x1440 @ 360Hz , 2560x1440 @ 480Hz , 1920x1080 @ 600Hz |
DisplayPort Max Refresh Rates (HDR) | 7680x4320 @ 60Hz , 3840x2160 @ 240Hz , 3440x1440 @ 360Hz , 2560x1440 @ 480Hz , 1920x1080 @ 600Hz |
HDMI® Version | 2.1 |
HDCP Version Supported | 2.3 |
USB Type-C® DisplayPort™ Alternate Mode | Yes |
Multi-Monitor Support | Yes |
Max Displays | 4 |
AMD FreeSync™ | Yes |
Wireless Display | Miracast |
Max Video Encode Bandwidth (SDR) | 1080p630 8bpc H.264, 1440p373 8bpc H.264, 2160p175 8bpc H.264, 1080p630 8bpc H.265, 1440p373 8bpc H.265, 2160p175 8bpc H.265, 4320p43 8bpc H.265, 1080p864 8/10bpc AV1, 1440p513 8/10bpc AV1, 2160p240 8/10bpc AV1, 4320p60 8/10bpc AV1 |
Max Video Decode Bandwidth | 1080p60 8bpc MPEG2, 1080p60 8bpc VC1, 1080p786 8/10bpc VP9, 2160p196 8/10bpc VP9, 4320p49 8/10bpc VP9, 1080p1200 8bpc H.264, 2160p300 8bpc H.264, 4320p75 8bpc H.264, 1080p786 8/10bpc H.265, 2160p196 8/10bpc H.265, 4320p49 8/10bpc H.265, 1080p960 8/10bpc AV1, 2160p240 8/10bpc AV1, 4320p60 8/10bpc AV1 |
AMD SmartAccess Memory | Available |
