| Printer |
| Printing Resolution | 4 800 (horizontal)*1 x 1 200 (vertical) dpi |
| Print Head / Ink | Number of Nozzles: | Total 1 472 nozzles |
| Ink Bottles | GI-790 (Black, Cyan, Magenta, Yellow) |
| Print Speed*2 | Document: Col | ESAT / Simplex | 5.0 images per minute |
| Based on ISO / IEC 24734 | Document: B / W | ESAT / Simplex | 8.8 images per minute |
| Printable Width | Bordered: | 203.2mm |
| Borderless: | 216mm |
| Printable Area | Borderless Printing*3 | Top / Bottom / Right / Left margin: each 0mm (Supported Paper Size: A4 / Letter /10.16 x 15.24 cm/ 12.7 x 17.78cm / 20.32 x 25.4cm / Square (12.7 x 12.7cm) / Business Card) |
| Bordered Printing | Top margin: 3mm, |
| Bottom margin: 5mm, |
| Left / Right margin: each 3.4mm |
| (Letter / Legal: Left: 6.4mm, Right: 6.3mm) |
| Recommended Printing Area | Top margin: | 31.2mm |
| Bottom margin: | 32.5mm |
| Paper Size | A4, A5, B5, Letter, Legal, 10.16cm x 15.24cm, 12.70cm x 17.78cm, 20.32cm x 64.51cm(25.4in), Envelopes (DL, COM10), Square (12.7 x 12.7 cm), Business Card, Custom size (width 55 - 215.9mm, length 89 - 676mm) |
| Paper Handling (Rear Tray) | Plain Paper | A4, A5, B5, Letter = 100, Legal = 10 |
| (Number) | High Resolution Paper (HR-101N) | A4, Letter = 80 |
| | Photo Paper Plus Glossy II (PP-201) | A4, Letter = 10, 10.16cm x 15.24cm= 20, 12.70cm x 17.78cm, 20.32cm x 25.40 = 10, Square (12.70cm x 12.70cm) = 20 |
| | Photo Paper Plus Semi-Gloss (SG-201) | A4, Letter = 10, 10.16 x 15.24cm = 20, 12.70cm x 17.78cm, 20.32 x 25.4cm = 10 |
| | Matte Photo Paper (MP-101) | A4, Letter = 10, 10.16cm x 15.24cm= 20 |
| | Envelope | European DL / US Com. #10 = 10 |
| | Glossy Photo Paper "Everyday Use" (GP-508) | A4 = 10, 10.16 x 15.24cm = 20 |
| | Photo Paper Plus Glossy II (PP-208) | A4, 10.16 x 15.24cm = 10 |
| | Photo Sticker | PS-108, PS-308R, PS-208, PS-808 = 1 |
| Paper Weight | Rear Tray | Plain Paper: 64 - 105g/m2, Canon specialty paper: paper weight: 275g/m2 Photo Paper Plus Glossy II (PP-201) |
| Ink End Sensor | Dot count |
| Print Head Alignment | Manual |
| System Requirements | Windows: | Windows 10, Windows 8.1, Windows 7 SP1 |
| General Specifications | |
| Interface | USB 2.0 Hi-Speed |
| Paper Output Tray | A4, Letter = 50, Legal = 10 |
| Operating Environment*4 | Temperature: | 5 - 35∞C |
| Humidity: | 10 - 90% RH (no dew condensation) |
| Recommended Environment*5 | Temperature: | 15 - 30∞C |
| Humidity: | 10 - 80% RH (no dew condensation) |
| Storage Environment | Temperature: | 0 - 40∞C |
| Humidity: | 5 - 95% RH (no dew condensation) |
| Quiet Mode | Available |
| Acoustic Noise (PC Print)*6 | Plain Paper (A4, B/W) | 54.5dB |
| Power | AC 100 - 240V; 50 / 60Hz |
| Power Consumption | Connection to PC | USB |
| OFF: | 0.2W |
| Standby (scanning lamp is off): | 0.6W |
| (USB connection to PC) |
| Standby (all ports connected, scanning lamp is off) | 0.6W |
| Printing*7: G1010 | 11W |
| Typical Electricity Consumption (TEC)*8 | 0.1kWh |
| Environment | Regulation: | RoHS (EU, China)*, WEEE (EU)* |
| *To be fixed |
| Eco-Label: | Energy Star* |
| *To be fixed |
| Dimension (W x D x H) | Factory configuration | 445 x 330 x 135mm |
| Output / ADF trays extended | 445 x 529 x 253mm |
| Weight | 4.8kg |
