Product Collection	IntelÆ Coreô i9 Processors (14th gen)
Code Name	Products formerly RAPTOR LAKE
Vertical Segment	Desktop
Processor Number	i9-14900K
Lithography	Intel 7
CPU Specifications
Total Cores	24
# of Performance-cores	8
# of Efficient-cores	16
Total Threads	32
Max Turbo Frequency	6 GHz
IntelÆ Thermal Velocity Boost Frequency	6 GHz
IntelÆ Turbo Boost Max Technology 3.0 Frequency á	5.8 GHz
Performance-core Max Turbo Frequency	5.6 GHz
Efficient-core Max Turbo Frequency	4.4 GHz
Performance-core Base Frequency	3.2 GHz
Efficient-core Base Frequency	2.4 GHz
Cache	36 MB IntelÆ Smart Cache
Total L2 Cache	32 MB
Processor Base Power	125 W
Maximum Turbo Power	253 W
Embedded Options Available	No
Memory Specifications
Max Memory Size (dependent on memory type)	192 GB
Memory Types	Up to DDR5 5600 MT/s Up to DDR4 3200 MT/s
Max # of Memory Channels	2
Max Memory Bandwidth	89.6 GB/s
ECC Memory Supported á	Yes
GPU Specifications
Graphics Base Frequency	300 MHz
Graphics Max Dynamic Frequency	1.65 GHz
Graphics Output	eDP 1.4b \| DP 1.4a \| HDMI 2.1
Execution Units	32
Max Resolution (HDMI)á	4096 x 2160 @ 60Hz
Max Resolution (DP)á	7680 x 4320 @ 60Hz
Max Resolution (eDP - Integrated Flat Panel)á	5120 x 3200 @ 120Hz
DirectX* Support	12
OpenGL* Support	4.5
OpenCL* Support	3
Multi-Format Codec Engines	2
IntelÆ Quick Sync Video	Yes
IntelÆ Clear Video HD Technology	Yes
# of Displays Supported á	4
Device ID	0xA780
Expansion Options
Direct Media Interface (DMI) Revision	4
Max # of DMI Lanes	8
Scalability	1S Only
PCI Express Revision	5.0 and 4.0
PCI Express Configurations á
