Description
Specifications
Category | Specification |
---|---|
Model Number | PH-NV523TG_DBK02 |
UPC Code | 886523303466 |
Case Dimensions (DxWxH) | 528 × 239 × 477 mm20.8 × 9.4 × 18.8 in |
Form Factor | Mid Tower |
Motherboard Support | E-ATX* (up to 280mm), ATX, Micro-ATX, Mini-ITX*E-ATX limited without GPU support bracket |
Materials | Steel chassis, Tempered glass |
Side Window | Yes |
PCI Slots | 7 |
Vertical GPU Support | Up to 3 slots (Riser cable sold separately) |
Drive Bays | - 2.5": 4- 3.5": 3 |
Front I/O Ports | - 1 × USB-C 3.2 Gen 2- 2 × USB 3.0- Microphone / Headphone- D-RGB Mode Button- D-RGB Color Button- Power Button |
Fan Support (120mm) | - Total: 8- Top: 3- Side: 3- Rear: 1- Bottom: 1 |
Fan Support (140mm) | Not supported |
Pre-installed Fans | Not listed |
Radiator Support (120mm) | - Top: up to 360mm- Side: up to 360mm- Rear: 120mm |
Radiator Support (140mm) | Not supported |
Radiator Dimensions | - Top: 134 × 430 × 62 mm- Side: 130 × 420 × 62 mm- Rear: 132 × 170 mm |
CPU Cooler Clearance | 180 mm / 7.08 in |
GPU Clearance | - Length: 440 mm / 17.32 in- Height: 170 mm / 6.69 in |
PSU Clearance | 230 mm / 9.05 in |
Net Weight | 11.28 kg / 24.9 lbs |
Gross Weight | 13.97 kg / 30.8 lbs |
Warranty | 5 Years (Limited) |
Scope of Delivery | - 1 × NV5 Chassis- 6 × Zip ties- 1 × GPU support bracket- Assorted screws and standoff tool |
