Description
Product Description:
🧠 Advanced Controller & Cache: Samsung Presto 5-core controller with 8 GB LPDDR4X DRAM for smooth multitasking
💾 Massive Storage & Endurance: 8 TB V-NAND TLC flash with 4,800 TBW for long-term reliability
🔐 Enterprise-Grade Security: AES-256 hardware encryption, TCG/Opal 2.0, and Microsoft eDrive support
🔥 Thermal & Power Efficiency: Optimized for PCIe 5.0 with improved heat management and 49% better power efficiency
💻 Universal Compatibility: M.2 2280 form factor fits desktops, laptops, and PS5; supports NVMe 2.0, TRIM, and SMART
Product Specifications:
| Specification | Details |
| Brand | Samsung |
| Model | 9100 PRO (MZ-VAP8T0BW) |
| Capacity | 8 TB |
| Form Factor | M.2 2280 |
| Interface | PCIe 5.0 x4, NVMe 2.0 |
| Controller | Samsung Presto 5-core ARM Cortex-R8 |
| NAND Flash | Samsung V-NAND TLC |
| DRAM Cache | 8 GB LPDDR4X |
| Sequential Read/Write | Up to 14,800/13,400 MB/s |
| Random IOPS | Up to 2,200K read / 2,600K write |
| Endurance | 4,800 TBW |
| Encryption | AES-256, TCG/Opal 2.0, Microsoft eDrive |
| Operating Temperature | 0–70 °C |
| Supported Features | NVMe 2.0, TRIM, SMART, Device Sleep |
| Country of Origin | South Korea |
| Model Number | MZ-VAP8T0BW |
| Warranty | 5 Years |
| Weight | 9.5 g |
