7.1 CH HD Audio, Realtek ALC1220 Codec, Blu-ray support, Surge Protection
LAN
Gigabit LAN (Realtek RTL8111H), Wake-On-LAN, Lightning/ESD Protection
Wireless
Intel 802.11ac WiFi, Dual-band 2.4/5 GHz, Bluetooth 4.2, speed up to 433 Mbps
Expansion Slots
2 x PCIe x16 (Gen4/Gen3), 1 x PCIe x1, AMD Quad CrossFireX
Storage
4 x SATA3 6Gb/s, 1 x Hyper M.2 (Gen4x4/Gen3x4)
I/O Ports (Rear)
2 x Antenna Ports, 1 x PS/2 Mouse/Keyboard, 1 x HDMI, 4 x USB 3.2 Gen1, 2 x USB 2.0, 1 x RJ-45 LAN, Audio Jacks
Cooling
1 x CPU Fan Connector, 3 x Chassis/Water Pump Fan Connectors, Smart Fan Control
Connectors
1 x COM, 1 x SPI TPM, 2 x RGB LED, 2 x Addressable LED, 2 x USB 3.2 Gen1 Headers, 2 x USB 2.0 Headers, 24-pin ATX, 8-pin 12V
Form Factor
Micro ATX, 9.6" x 9.6", 2oz Copper PCB
Software
ASRock Utility (A-Tuning), Polychrome SYNC
BIOS
256Mb UEFI, Plug and Play, ACPI 5.1, Jumperfree, Multi-Voltage Adjustment
OS Support
Windows 10/11 64-bit
Accessories
I/O Shield, 2 x SATA cables, 2 x WiFi Antennas, M.2 Screw
