Specifications
| Specification | Details |
|---|---|
| Product Dimensions (L×W×H) | 144 × 147 × 164 mm |
| Heatsink Dimensions (L×W×H) | 140 × 110 × 160 mm |
| Net Weight | 1772 g |
| Heatpipe | Ø6 mm × 7 pcs |
| Fan Dimensions (L×W×H) | 140 × 140 × 25 mm / 120 × 120 × 25 mm |
| Fan Speed (Performance Mode) | 500 ~ 1800 RPM ±10% / 500 ~ 1700 RPM ±10% |
| Fan Airflow (Performance Mode) | 61.25 CFM / 58.06 CFM |
| Fan Air Pressure (Performance Mode) | 3.76 mmAq / 2.1 mmAq |
| Overall Noise (Performance Mode) | ≤ 29.3 dB(A) |
| Fan Speed (Quiet Mode) | 500 ~ 1450 RPM ±10% / 500 ~ 1350 RPM ±10% |
| Fan Airflow (Quiet Mode) | 48.55 CFM / 46.75 CFM |
| Fan Air Pressure (Quiet Mode) | 2.46 mmAq / 1.35 mmAq |
| Overall Noise (Quiet Mode) | ≤ 22.6 dB(A) |
| Fan Connector | 4-pin PWM |
| Bearing Type | Fluid Dynamic Bearing |
| Motor Type | 6-Pole Fan Motor |
| Fan Rated Voltage | 12 VDC |
| Fan Rated Current | 0.2 A / 0.2 A |
| Fan Power Consumption | 2.4 W / 2.4 W |
| Rated Voltage | 12 VDC |
| Power Consumption (Performance Mode) | 4.8 W |
| Power Consumption (Quiet Mode) | 3.6 W |
| EAN | 6933412729433 |
| P/N | R-ASN4-WHNVNN-GJD |
