Description
Features
- UHD 4K display with resolution of 3840 × 2160.
- Anti-glare and anti-blocking design to ensure smooth interaction.
- Dual systems of Android and Windows（Optional with OPS） saving cost and easy to use, video conference software are recommonded to run under Windows system.
- Quick response, at most 50-points touch control and smooth writing experience.
- Built-in network switch chip saves a network switch.
- All-in-one design with tempered glass and intelligent temperature control, making it environmental-friendly and safety-guaranteed, support blue light protection.
- EDLA Certified
Specifications
| Category | Specification |
|---|---|
| Product Model | DS-D5C86RB/B |
| Screen Size | 86 inch |
| Panel Type | VA |
| Resolution | 3840 × 2160 @ 60 Hz (4K UHD) |
| Pixel Pitch | 0.1645 mm (H) × 0.4935 mm (V) |
| Brightness | 400 cd/m² (Typ.) |
| Color Depth | 10-bit |
| Display Colors | 1.07 Billion |
| Response Time | 5 ms |
| Contrast Ratio | 5000:1 (Static) / 30,000:1 (Dynamic) |
| Color Gamut | 72% NTSC (CIE1931) |
| Refresh Rate | 60 Hz |
| Viewing Angle | 178° (H) / 178° (V) |
| Surface Glass | 9H Hardness, Anti-Glare, 25% Haze, Zero Lamination |
| Display Area | 1895.04 mm × 1065.96 mm |
| Working Duration | 7 × 16 Hours |
| Lifespan | 50,000 Hours |
| Touch Screen | Infrared, Up to 50-point Multi-touch |
| Touch Response Time | ≤ 2 ms |
| Minimum Touch Object Size | ≥ 1.5 mm |
| Built-in System | Android 13.0 |
| Processor | Quad-core Cortex-A76 × 4 (2.4 GHz) + Quad-core Cortex-A55 × 4 (1.8 GHz) |
| Memory | 8 GB RAM |
| Storage | 128 GB |
| GPU | Mali-G610 MC4 |
| Camera | 48MP Photo, 8MP Video, 4K Max, 93.4° Field of View |
| Microphone | 8-Mic Array, 12m Voice Pickup |
| Speakers | 2 × 20W + 1 × 25W Built-in |
| Bluetooth | BLE 5.1 |
| NFC | Supported (Android Screen Mirroring) |
| Light Sensor | Yes |
| Image Tech | 3D Noise Reduction, Face Detection, Auto WB, De-fogging, Shadow Correction |
| Audio Tech | Echo Cancellation, Noise Reduction, AGC, Beamforming |
| Video/Audio Inputs | HDMI 2.0 ×3, VGA ×1, DP 1.2 ×1, Audio In ×1 |
| Video/Audio Outputs | HDMI Out (2.0) ×1, Audio Out ×1, SPDIF Out ×1 |
| Control Ports | TOUCH-USB 3.0 ×3, RS232 ×1 |
| Network | LAN ×2 (1000 Mbps), Wi-Fi 6 (2.4G/5G, 2×2 MIMO) |
| Data Ports | USB 3.0 ×4, USB 2.0 ×1, Type-C ×2 (15W and 65W Charging) |
| Power Supply | 100–240V AC, 50/60 Hz |
| Average Power Consumption | < 205W |
| Standby Consumption | ≤ 0.5W |
| Working Temperature | 0 °C to 40 °C |
| Working Humidity | 10%–90% RH |
| VESA Mount | 800 mm × 600 mm (M8-25mm Screws) |
| Product Dimensions | 1960.44 mm × 1173.74 mm × 82.5 mm |
| Package Dimensions | 2147 mm × 1335 mm × 213 mm |
| Net Weight | 65.13 kg |
| Gross Weight | 82.6 kg |
| Accessories | Wall Mount Bracket, Hook, Touch Pen, 3M USB Cable, 3.5M HDMI Cable, Power Cable, Bluetooth Remote, User Manual |
