About This Product
This pocket-sized multi-adapter provides all the ports you need for maximum productivity. It has 9 functions in 1 sleek adapter. It allows you to connect your laptop to a 4K monitor. It also connects to an ultrawide monitor. The USB-C™ multi-adapter gives you 2 USB™ Type-A ports for additional peripherals and 1 USB™ Type-A port with BC 1.2 to fast-charge your mobile device.
With USB-C® Power Delivery 3.0, the adapter offers both upstream and downstream charging when connected to a USB-C® power adapter. It also provides direct access to a wired network and to your SD™ & microSD™ memory cards.
The JCD383 is perfect for small workspaces, home offices and for on-the-go!
Features
- • 8 ports with 9 functions
- • USB-C™ power delivery 3.0 provides charging power to the connected devices as well as data transfer
- • Easily add a 4K HDMI™ video output
- • Reliable network connectivity via the Gigabit Ethernet port
- • 2 - USB™ Type-A with BC 1.2 to fast-charge your mobile devices
- • USB™ 3.1 Gen 1 provides up to 5 Gbps transfer speed, which is 10x faster than USB™ 2.0
- • Direct access to SD™ & microSD™ memory cards for data storage and transfer
System Requirements:
• Available USB-C™ port that supports DisplayPort™ Alt Mode and USB™ Power Delivery 2.0 or 3.0.
Please refer to the manufacturer of your hardware for more information on your device
Special Notes:
- • The adapter can connect to a USB-C™ port that doesn’t support Power Delivery but it will not pass power through the connected device
- • A 4K-capable display is required for obtaining the 3840 x 2160 resolution
- • If you are using a high-powered USB™ device, attach the USB-C™ power adapter to the power delivery port to ensure maximum performance. When using your USB-C™ power adapter, the multi-adapter powers both the adapter (with attached peripherals) and your laptop
- • To ensure files copy completely, do not remove the USB-C™ power adapter while copying files. For maximum performance, use a computer and USB-C™ power adapter equipped with PD 3.0
- • The device may become warm to moderately hot while transferring bulk data or while a USB-C™ power supply is plugged in
| Hardware | |
| Warranty | 2-Year Limited |
| Host Connector | 1 - USB-C™ Male |
| Video Output | 1 - HDMI™ Female |
| Power Source | Bus-powered or self-powered |
| Network Interface | RJ45 (Gigabit Ethernet) |
| Audio Supported | Yes |
| Ports | 1 - USB-C™ 3.0 (upstream & downstream charging, power delivery 3.0 and data transfer) 2 - USB™ Type-A 3.1 Gen 1 1 - USB™ Type-A 3.1 Gen 1 with BC 1.2 1 - SD™ & microSD™ 1 - 4K HDMI™ 1 - RJ45 Gigabit Ethernet |
| Performance | |
| Maximum Display Resolution | 3840 x 2160 |
| Maximum Display Refresh Rate | 30 Hz |
| Maximum Data Transfer Rate | 5 Gbps |
| Displays Supported | 1 |
| Compatible Networks | 10/100/1000 Base-T, auto-negotiating |
| Audio Channel | 2.1 via HDMI™ |
| Power | |
| Power Delivery | 100W |
| Power Consumption | ≤ 500 mA |
| Input Current | Up to 5A |
| Input Voltage | Up to 20V |
| Output Current | Up to 4.25A |
| Output Voltage | Up to 20V |
| Physical Specifications | |
| Color | Silver |
| Enclosure Type | Aluminum |
| Cable Length | 5.4 in. (137 mm) |
| Product Height | 4.13 in. (105 mm) |
| Product Width | 1.97 in. (50 mm) |
| Product Depth | 0.65 in. (16.5 mm) |
| Product Weight | 2.75 oz (78g) |
| Storage Temperature | 14 to 149°F (-10 to 65°C) |
| Storage Humidity | < 85% non-condensing |
| Operating Temperature | 32 to 118°F (0 to 48°C) |
| Operating Humidity | < 85% non-condensing |
Package Contents
- • 1 - JCD383 USB-C™ 9-in-1 Multi Adapter
- • 1 - Quick Installation Guide
