Description
Key Features
- 16 x 3.5" SATA III HDD Bays
- 6 x 2.5" SATA III SSD Bays
- 2.6 GHz Intel Xeon E-2378 8-Core CPU
- 64GB ECC DDR4 RAM
- 2 x 2.5 GbE & 2 x 10 GbE Ports
- 4 x USB-A 3.2 Gen 2 Ports
- RAID 0, 1, 5, 6, 10, 50, 60 & Single
- Up to 9961 MB/s Read & 9670 MB/s Write
- AES-NI & AES 256-Bit Volume Encryption
- QuTS hero Operating System
Specifications
Category | Specification |
---|---|
RAID | Yes, Supported Modes: 0 / 1 / 5 / 6 / 10 / 50 / 60 |
Number of Bays | 6x 2.5" SATA III 16x 3.5" SATA III |
Inputs/Outputs | 2x RJ45 10GbE 2x RJ45 2.5GbE 4x USB-A 3.1/3.2 Gen 2 |
Media Card Slots | No |
PCI Expansion | 1x PCIe 4.0 x8 2x PCIe 4.0 x4 |
CPU | Intel Xeon E-2378 (8-Core, Up to 2.6 GHz) |
Memory | 64 GB ECC DDR4 |
RAM Configuration | 4x User-Replaceable 16 GB 4 Slots, Up to 128 GB |
Link Aggregation / Failover | No |
iSCSI Support | Yes, 256 LUN / 256 Target |
Operating System | QuTS hero |
OS Compatibility | macOS 10.10 or Later Ubuntu 14.4 or Later CentOS 7 or Later Linux, UNIX Windows 7 or Later Windows Server 2008 R2 or Later |
Mobile App | Yes: Android & iOS |
Encryption | 256-Bit AES, AES-NI |
Security Features | No |
VPN Connections | 100 (Client) |
Power Supply | 2 x 550W (Supports Redundancy) |
Operating Conditions | 32 to 72°F / 0 to 40°C 5 to 95% Humidity |
Storage Conditions | -4 to 158°F / -20 to 70°C |
Certifications | No |
Cooling | 1x 80 mm Fan 3x 60 mm Fans |
Dimensions | 24.8 x 19.02 x 5.24" / 63 x 48.31 x 13.31 cm |
Weight | 34.5 lb / 15.6 kg (without Drives) |
Package Weight | 49 lb |
Box Dimensions | 29.25 x 23.25 x 12.25" |
