Description
- F-LUX Platform: Advanced case structure for excellent airflow + 5 x 120 mm fans included
- Provide mass airflow to your components with room for up to 9 x 120 mm fans
- Electroplating-processed LED on the top left-hand side presents a Sci-Fi vibration
- Ready for radiator up to 360 mm in front, 360 mm on top & 120 mm in rear
- With room for 2.5" SSDs: 3 & 3.5" HDDs / 2.5" SSDs (convertible): 3 / 2
Specifications:
| Dimensions | 463 x 220 x 486 mm (DWH) |
| Form Factor | Mid Tower |
| Materials | Steel + Plastic |
| Mainboard Support | ATX, M-ATX, ITX |
| Front Access & Controls | Power, LED Control Button, 2 x USB3.0, HD-AUDIO |
| Side Panel | 4 mm Tempered Glass Side Panel |
| Expansion Slots | 7 |
| 5.25" | 1 |
| 3.5" /2.5" | 03-Feb |
| 2.5" | 3 |
| Front | 3 x 120 mm / 2 x 140 mm |
| Top | 3 x 120 mm / 2 x 140 mm (w/o ODD and w/o ODD bracket) |
| 2 x 120 mm / 2 x 140 mm (w/o ODD but with ODD bracket) | |
| 2 x 120 mm / 1 x 140 mm (When ODD is installed) | |
| Power Supply Shroud | 2 x 120 mm |
| Rear | 1 x 120 mm |
| Pre-installed Fans | 3 x 120 mm fans in front |
| 1 x 120 mm fan (Reverse Fan) on PSU shroud | |
| & 1 x 120 mm fan in rear | |
| Front | 120/240/280/360 mm (? 55 mm thickness when fans are installed outside of front panel) |
| (? 30 mm thickness when fans are installed inside of front panel) | |
| [Max Radiator Length ? 405 mm] | |
| Top | 240/280/360 mm (w/o ODD and w/o ODD bracket) |
| 240/280 mm (w/o ODD but with ODD bracket) | |
| 120 mm(When ODD is installed) | |
| [Max Radiator Length ? 405 mm] | |
| Rear | 120 mm |
| Max GPU Length | ? 405 mm |
| Max CPU Cooler Height | ? 175 mm |
| Max PSU Length | ? 205 mm |
| Dust Filter | Front / Top / Bottom / Right Hand Side |
| Net Weight | 7.55KG |
| Gross Weight | 8.7KG |
| Warranty | 2 years |
