Specifications
| Model name | TUF-RTX5060TI-O16G-GAMING |
| Graphics Engine | NVIDIA® GeForce RTX™ 5060 Ti |
| CUDA cores | 4608 |
| OpenGL® | OpenGL® 4.6 |
| Engine Clock | OC mode: 2692MHz Default mode: 2662MHz (Boost Clock) |
| Memory Interface | 128 bit |
| Video Memory | 16GB GDDR7 |
| Memory Speed | 28 Gbps |
| AI Performance | 785 |
| Power Connector | 1 x 16-pin |
| I/O | 1 x Native HDMI 2.1b 3 x Native DisplayPort 2.1b |
| HDCP Compliant | HDCP 2.3 |
| Digital Max. Resolution | 7680 x 4320 |
| Maximum Display Support | 4 |
| NVLink/ Crossfire Support | N/A |
| Recommended PSU | 550W |
| Bus Standard | PCIE 5.0 |
| Package Contents | 1 x Speedsetup Manual 1 x TUF Graphics Card Holder 1 x TUF Velcro Hook & Loop 1 x TUF Gaming Certificate 1 x Thank You Card 1 x Adpater Cable (1 to 2) |
| Software Bundled | ASUS GPU Tweak III & MuseTree & GeForce Game Ready Driver & Studio Driver: please download all software from the support site. |
| Slot | 3.1 slot |
| Dimension | |
| Card Size (mm/inch) | 302 x 133.5 x 62mm |
| Color Box (mm) | 421 x 227 x 88 mm |
| Weight | |
| Single Card (KG) | 1.147kg |
| Product Weight (with packing) (KG) | 1.907kg |
| Note | * Our wattage recommendation is based on a fully overclocked GPU and CPU system configuration. For a more tailored suggestion, please use the “Choose By Wattage” feature on our PSU product page: https://rog.asus.com/event/PSU/ASUS-Power-Supply-Units/index.html * All specifications are subject to change without notice. Please check with your supplier for exact offers. Products may not be available in all markets. If you do not use the latest and current specifications of ASUS products, you shall be liable for all loss and damage claimed by third party to ASUS based on false advertising or any other issues caused from using false specifications of ASUS products. |
| Regulation | ■S-AT2-001 GreenASUS Hazardous Substances Free(HSF) Technical Standard(Global RoHs,China RoHS,EU REACH,J-MOSS) ■WEEE |
| Certifications | ■ FCC ■ CE ■ C-TICK ■ BSMI ■ KCC ■ VCCI |
