Description
| CPU | AMD Socket AM5 for AMD Ryzenô 7000 Series Desktop Processors* |
| * Refer to www.asus.com for CPU support list. | |
| Chipset | AMD X670 |
| Memory | 4 x DIMM, Max. 128GB, DDR5 |
| 6400+(OC)/ 6200(OC)/ 6000(OC)/ 5800(OC)/ 5600(OC)/ 5400(OC)/ 5200/ 5000/ 4800MHz, Un-buffered Memory* | |
| Dual Channel Memory Architecture | |
| Supports AMDÆ EXTended Profiles for Overclocking (EXPOô) | |
| OptiMem II | |
| * Supported memory types, data rate(Speed), and number of DRAM module vary depending on the CPU and memory configuration, for more information refer to www.asus.com for memory support list. | |
| * Non-ECC, Un-buffered DDR5 Memory supports On-Die ECC function | |
| Graphics | 1 x HDMIÆ port* |
| 2 x USB4Æ ports support USB Type-CÆ display outputs** | |
| *Supports 4K@60Hz as specified in HDMI 2.1. | |
| **VGA resolution support depends on processorsí or graphic cardsí resolution. | |
| Expansion Slots | AMD Ryzenô 7000 Series Desktop Processors |
| 2 x PCIe 5.0 x16 slots (supports x16 or x8/x8 mode(s)* | |
| AMD X670 Chipset | |
| 1 x PCIe 4.0 x1 slots | |
| * When the PCIe 5.0 M.2 card is installed on the PCIEX16_2 slot, PCIEX16_1 will run x8 only. | |
| Storage | Total supports 5 x M.2 slots and 6 x SATA 6Gb/s ports* |
| AMD Ryzenô 7000 Series Desktop Processors | |
| M.2_1 slot (Key M), type 2242/2260/2280 (supports PCIe 5.0 x4 mode) | |
| M.2_2 slot (Key M), type 2242/2260/2280 (supports PCIe 5.0 x4 mode) | |
| PCIe 5.0 M.2 slot (Key M) via PCIe 5.0 M.2 card, type 2242/2260/2280/22110 (supports PCIe 5.0 x4 mode)** | |
| AMD X670 Chipset | |
| M.2_3 slot (Key M), type 2242/2260/2280 (supports PCIe 4.0 x4 ) | |
| M.2_4 slot (Key M), type 2242/2260/2280 (supports PCIe 4.0 x4 ) | |
| 6 x SATA 6Gb/s ports | |
| *AMD RAID Xpert2 Technology supports both NVMe RAID 0/1/10 and SATA RAID 0/1/10. | |
| **Performance may vary depending on the SSDís firmware version and the system hardware & system configuration, for more information refer to www.asus.com for device support list. | |
| Ethernet | 1 x IntelÆ 2.5Gb Ethernet |
| ASUS LANGuard | |
| Wireless & Bluetooth | Wi-Fi 6E |
| 2◊2 Wi-Fi 6E (802.11 a/b/g/n/ac/ax) | |
| Supports 2.4/5/6GHz frequency band* | |
| Bluetooth v5.2 | |
| * WiFi 6E 6GHz regulatory may vary between countries, and function will be ready in Windows 11 or later. | |
| USB | Rear USB (Total 12 ports) |
| 2 x USB4Æ ports with IntelÆ JHL8540 USB4Æ controller (2 x USB Type-CÆ) | |
| 1 x USB 3.2 Gen 2◊2 port(s) (1 x USB Type-CÆ) | |
| 9 x USB 3.2 Gen 2 port(s) (8 x Type-A + 1 x USB Type-CÆ) | |
| Front USB (Total 11 ports) | |
| 1 x USB 3.2 Gen 2◊2 connector (supports USB Type-CÆ with up to 60W PD/QC4+)* | |
| 2 x USB 3.2 Gen 1 headers) support additional 4 USB 3.2 Gen 1 ports | |
| 3 x USB 2.0 headers support additional 6 USB 2.0 ports | |
| *To support 60W, please install the power cable to the 6-pin PCIe Graphics Card connector or else only 27W can be supported. | |
| Audio | ROG SupremeFX 7.1 Surround Sound High Definition Audio CODEC ALC4082 |
| ñ Impedance sense for front and rear headphone outputs | |
| ñ Supports: Jack-detection, Multi-streaming, Front Panel Jack-retasking | |
| ñ High quality 120 dB SNR stereo playback output and 113 dB SNR recording input | |
| ñ Supports up to 32-Bit/384 kHz playback | |
| Audio Features | |
| ñ SupremeFX Shielding Technology | |
| ñ ESSÆ ES9218 QUAD DAC | |
| ñ Gold-plated audio jacks | |
| ñ Rear optical S/PDIF out port | |
| ñ Premium audio capacitors | |
| ñ Audio cover | |
| Back Panel I/O Ports | 2 x USB4Æ ports with IntelÆ JHL8540 USB4Æ controller (2 x USB Type-CÆ) |
| 1 x USB 3.2 Gen 2◊2 port (1 x USB Type-CÆ) | |
| 9 x USB 3.2 Gen 2 ports (8 x Type-A + 1 x Type-CÆ) | |
| 1 x HDMIÆ port | |
| 1 x Wi-Fi Module | |
| 1 x IntelÆ 2.5Gb Ethernet | |
| 5 x Gold-plated audio jacks | |
| 1 x Optical S/PDIF out port | |
| 1 x BIOS FlashBackô button | |
| 1 x Clear CMOS button | |
| Internal I/O Connectors | Fan and Cooling related |
| 1 x 4-pin CPU Fan header | |
| 1 x 4-pin CPU OPT Fan header | |
| 1 x 4-pin AIO Pump header | |
| 4 x 4-pin Chassis Fan headers | |
| 1 x W_PUMP+ header | |
| 1 x 2-pin Water In header | |
| 1 x 2-pin Water Out header | |
| 1 x 3-pin Water Flow header | |
| Power related | |
| 1 x 24-pin Main Power connector | |
| 2 x 8-pin +12V Power connector | |
| 1 x 6-pin PCIe Power connector | |
| Storage related | |
| 4 x M.2 slots (Key M) | |
| 6 x SATA 6Gb/s ports | |
| USB | |
| 1 x USB 3.2 Gen 2◊2 connector (supports USB Type-CÆ) | |
| 2 x USB 3.2 Gen 1 headers support additional 4 USB 3.2 Gen 1 ports | |
| 3 x USB 2.0 headers support additional 6 USB 2.0 ports | |
| Miscellaneous | |
| 3 x Addressable Gen 2 headers | |
| 1 x Alteration Mode Switch | |
| 1 x Aura RGB header | |
| 1 x FlexKey button | |
| 1 x Front Panel Audio header (AAFP) | |
| 1 x ReTry button | |
| 1 x Start button | |
| 1 x 10-1 pin System Panel header | |
| 1 x Thermal Sensor header | |
| Special Features | Extreme OC Kit |
| ñ FlexKey button | |
| ñ ReTry button | |
| ñ Start button | |
| Extreme Engine Digi+ | |
| ñ 10K Black Metallic Capacitors | |
| ñ MicroFine Alloy Choke | |
| ASUS Q-Design | |
| ñ M.2 Q-Latch | |
| ñ PCIe Slot Q-Release | |
| ñ Q-Code | |
| ñ Q-Connector | |
| ñ Q-DIMM | |
| ñ Q-LED (CPU [red], DRAM [yellow], VGA [white], Boot Device [yellow green]) | |
| ñ Q-Slot | |
| ASUS Thermal Solution | |
| ñ M.2 heatsink backplate | |
| ñ M.2 heatsink | |
| ñ VRM heatsink design | |
| ASUS EZ DIY | |
| ñ BIOS FlashBackô button | |
| ñ Clear CMOS button | |
| ñ ProCool II | |
| ñ Pre-mounted I/O shield | |
| ñ SafeSlot | |
| ñ SafeDIMM | |
| Aura Sync | |
| ñ Aura RGB header | |
| ñ Addressable Gen 2 headers | |
| Front Panel USB 3.2 Gen 2◊2 with Quick Charge 4+ Support | |
| ñ Support: up to 60W charging* | |
| ñ Output: 5/9/15/20V max. 3A, PPS:3.3ñ21V max. 3A | |
| ñ Compatible with QC 4.0/3.0/2.0, PD3.0 and PPS | |
| * To support 60W, please install the power cable to 6-pin PCIe Graphics Card connector or can only support 27W | |
| Software Features | ROG Exclusive Software |
| ñ GameFirst VI | |
| ñ ROG CPU-Z | |
| ñ Sonic Studio III + Sonic Studio Virtual Mixer + Sonic Suite Companion | |
| ñ Sonic Radar III | |
| ñ DTSÆ Sound Unbound | |
| ñ BullGuard Internet Security (1-year full version) | |
| ASUS Exclusive Software | |
| Armoury Crate | |
| ñ AIDA64 Extreme (1 year full version) | |
| ñ Aura Creator | |
| ñ Aura Sync | |
| ñ Fan Xpert 4 with AI Cooling II | |
| ñ Power Saving | |
| ñ Polymo Lighting | |
| ñ Two-Way AI Noise Cancellation | |
| AI Suite 3 | |
| TPU | |
| DIGI+ Power Control | |
| Turbo app | |
| PC Cleaner | |
| MyAsus | |
| WinRAR | |
| UEFI BIOS | |
| ASUS EZ DIY | |
| ñ ASUS CrashFree BIOS 3 | |
| ñ ASUS EZ Flash 3 | |
| ñ ASUS UEFI BIOS EZ Mode | |
| BIOS | 256 Mb Flash ROM, UEFI AMI BIOS |
| Manageability | WOL by PME, PXE |
| Accessories | Cables |
| 1 x ARGB RGB extension cable | |
| 1 x RGB extension cable | |
| 4 x SATA 6Gb/s cables | |
| PCIe 5.0 M.2 Card with Heatsink | |
| 1 x PCIe 5.0 M.2 Card with heatsink | |
| 1 x M.2 screw package for PCIe 5.0 M.2 Card | |
| Additional Cooling Kit | |
| 1 x Thermal pad for M.2 | |
| Miscellaneous | |
| 1 x ASUS Wi-Fi moving antennas | |
| 3 x Rubber Packages for M.2 backplate | |
| 1 x Q-connector | |
| 1 x M.2 Q-Latch package | |
| 3 x M.2 Q-Latch packages for M.2 backplate | |
| 1 x ROG Graphics card holder | |
| 1 x ROG key chain | |
| 1 x ROG stickers | |
| 1 x ROG thank you card | |
| Installation Media | |
| 1 x USB drive with utilities and drivers | |
| Documentation | |
| 1 x User guide | |
| Operating System | WindowsÆ 11 64-bit, WindowsÆ 10 64-bit |
| Form Factor | ATX Form Factor |
| 12 inch x 9.6 inch ( 30.5 cm x 24.4 cm ) |
