SPECIFICATIONS
| MODEL | MPY-7501-SFHAGV |
| ATX VERSION | SFX 12V Ver. 3.42 |
| PFC | Active PFC |
| INPUT VOLTAGE | 90-264V |
| INPUT CURRENT | 10-5A |
| INPUT FREQUENCY | 47-63Hz |
| DIMENSIONS (L X W X H) | 100 x 125 x 63.5 mm |
| FAN SIZE | 92mm |
| FAN BEARING | FDB |
| EFFICIENCY | 90% @ Typical Load |
| 80 PLUS RATING | 80 PLUS Gold |
| ERP 2014 LOT 3 | Yes |
| OPERATING TEMPERATURE | 0-50∞C |
| POWER GOOD SIGNAL | 100 - 500 ms |
| HOLD UP TIME | 16ms |
| MTBF | >100,000 Hours |
| PROTECTIONS | OVP, OPP, SCP, OCP, UVP, OTP, Surge and Inrush Protection |
| REGULATORY | TUV, cTUVus, CE, BSMI, FCC, CCC, EAC, RCM, KCC, CB |
| ATX 24-PIN CONNECTORS | 1 |
| EPS 4+4 PIN CONNECTORS | 1 |
| EPS 8 PIN CONNECTOR | 1 |
| SATA CONNECTORS | 8 |
| PERIPHERAL 4-PIN CONNECTORS | 4 |
| PCI-E 6+2 PIN CONNECTORS | 4 |
| SERIES | V Gold Series, V SFX Gold Series |
| 80 PLUS | Gold |
| MODULAR | Full Modular |
| WATTAGE | 500 to 750W |
