Description
Specifications
| Specification | Details |
|---|---|
| Model Number | QUBE 500 Flatpack: Q500-KGNN-S00QUBE 500 Flatpack White: Q500-WGNN-S00 |
| Exterior Color | Black, White |
| Materials - Exterior | Steel, Plastic, Tempered Glass (TG) |
| Materials - Left Side Panel | Grey TG + Steel |
| Dimensions (L x W x H) | 406 × 231 × 415 mm (incl. protrusions)380 × 231 × 381 mm (excl. protrusions) |
| Volume | 33.44L (excl. protrusions) |
| Motherboard Support | ITX / Micro ATX / ATX / E-ATX (up to 296mm width with SFX PSU, 273mm with ATX PSU) |
| Expansion Slots | 7 |
| 3.5" Drive Bays | 4 |
| 2.5" Drive Bays | 3 |
| I/O Panel - USB Ports | 2× USB 3.2 Gen 1 Type-A1× USB 3.2 Gen 2x2 Type-C |
| I/O Panel - Audio In/Out | 1× 3.5mm Combo |
| Pre-installed Fans - Rear | QUBE 500 Flatpack: 1× 120mm (1800 RPM) SF Black PWMQUBE 500 Flatpack White: 1× 120mm (1800 RPM) SF White PWM |
| Fan Support - Front | 1× 120/140mm (2× with bottom PSU) |
| Fan Support - Top | 2× 120/140mm |
| Fan Support - Rear | 1× 120mm |
| Fan Support - Bottom | 2× 120/140mm |
| Fan Support - Left Side | 2× 120/140mm |
| Radiator Support - Front | 120/140mm (240/280mm with PSU at bottom) |
| Radiator Support - Top | 120/140/240/280mm (up to 53mm thickness) |
| Radiator Support - Rear | 120mm |
| Radiator Support - Bottom | 120/140/240/280mm |
| Radiator Support - Left Side | 120/140/240/280mm |
| Clearance - CPU Cooler | 164mm–172mm (remove water cooling bracket) |
| Clearance - PSU | 173mm to first GPU slot, 216mm max (without cable management), 332mm (bottom mount, without cable management) |
| Clearance - GFX | 365mm |
| Cable Routing - Behind Motherboard Tray | 29–32mm |
| Handle | QUBE 500 Flatpack: Black x1QUBE 500 Flatpack White: Grey x1 |
| Gem Mini | QUBE 500 Flatpack: Black x1QUBE 500 Flatpack White: Grey x1 |
| Dust Filters | Front, Top, Bottom, Right Side |
| Power Supply Support | SFX / SFX-L / ATX |
| Warranty | 2 years |
| Size | Mid Tower |
| Series | QUBE Series |
| Back Connector Motherboard Support | No |
