Description
Technical Details
| Product Name | FV270 RGB / FV270 RGB(White) | |
|---|---|---|
| Case Form Factor | Mid Tower | |
| Motherboard Type | Mini ITX / Micro ATX / ATX / CEB / E-ATX | |
| Dimensions (WxHxD) | 268 x 530 x 512 (mm) 10.6 x 20.9 x 20.2 (in) | |
| I/O Panel | Type C Gen 2 x 1, USB 3.0 x 2, 4 Pole Headset Audio Jack, RGB Button | |
| 3.5" Drive Bay | 2 | |
| 2.5" Drive Bay | 2+2 (converted from 3.5" drive bays) | |
| Expansion Slots | 7 (horizontal slots can be converted into vertical slots) | |
| Vertical GPU Support | Yes | |
| Cooling Fan Support | Top | 120mm x 3 / 140mm x 2 |
| M/B Side | 120mm x 2 / 140mm x 2 | |
| PSU Shroud | 120mm x 2 / 140mm x 2 | |
| Bottom | 120mm x 1 | |
| Rear | 120mm x 1 / 140mm x 1 | |
| Pre-installed Fans | M/B Side | 140mm Reversed ARGB PWM fan x 2 |
| Bottom | 120mm Reversed ARGB PWM fan x 1 | |
| Rear | 140mm ARGB PWM fan x 1 | |
| Speed | 500 (±200) - 1200 (±10%) RPM | |
| Connector | 5V 3 Pin (ARGB) / 4 Pin (Fan) | |
| Maximun Number of Fans | 9 | |
| Water Cooling Support | Top | 360mm / 280mm / 240mm / 140mm / 120mm |
| M/B Side | 280mm / 240mm / 140mm / 120mm | |
| PSU Shroud | 240mm / 120mm | |
| Bottom | - | |
| Rear | 140mm / 120mm | |
| PWM and RGB Hub Sync with M/B | Yes | |
| Max. Graphics Card Length | Horizontal | 420 (mm) / 16.5 (in) (Only fans at the M/B Side) 330 (mm) / 13 (in) (Radiator with fans at the M/B Side) |
| Vertical | 450 (mm) / 17.7 (in) | |
| Max. CPU Cooler Height | 180 (mm) / 7.1 (in) | |
| Max. PSU Length | 250 (mm) / 9.8 (in) | |
