Technical Spec
| Product Dimensions | 457.5×235×533.5mm(L×W×H) |
| Net Weight | 11.82Kg |
| Materials | ABS+SPCC+Tempered Glass |
| Motherboard Support | Mini-ITX / Micro-ATX / ATX ATX(Rear Connector)/Micro-ATX(Rear Connector) |
| Front I/O Ports | USB3.0×2、Gen2 Type-C x1、Audio/Mic×1 |
| 3.5" Drive Bays | 2+1 |
| 2.5" Drive Bays | 1+1 |
| Expansion Slots | 7 Slots |
| Pre-Installed Fans | Bottom: 2×120mm ARGB（Reverse Blade） |
| Fan Support | Top: 3×120mm/2×140mm Front: 2×140mm Rear: 1×140/1×120mm Bottom: 2×120mm |
| Radiator Support | Top: Pre-Installed 360mm Front: NA Rear: 120mm |
| CPU Cooler Height Limit | 175mm |
| GPU Size Limit | 413mm/388mm(With Front Fan) |
| Power Supply Type | ATX PS2（maximum length: 160mm）/SFX/SFX-L |
| Radiator Dimensions | 402×120×27 mm |
| Radiator Material | Aluminum |
| Tube length | 250 mm |
| Pump Dimensions | 118×80×76 mm |
| Pump Speed | 2500~3400 RPM±10% |
| Pump Connector | 4-pin PWM |
| Pump Rated Voltage | 12 VDC |
| Pump Rated Current | 0.29 A |
| Pump Power Consumption | 3.48 W |
| Fan Dimensions | 120×120×25 mm |
| Fan Speed | 500~2500 RPM±10% 0 rpm<5 % PWM |
| Fan Airflow | 73.41 CFM |
| Fan Air Pressure | 4.69 mmAq |
| Fan Noise | ≤35.63 dB(A) |
| Fan Connector | 4-pin PWM |
| Bearing Type | Fluid Dynamic Bearing |
| Fan Rated Voltage | 12 VDC |
| Fan Rated Current | 0.3 A |
| Fan Power Consumption | 3.6 W |
| LED Type | Addressable RGB LED |
| LED Connector | 3-pin(+5V-D-G) |
| LED Rated Voltage | 5 VDC |
| LED Power Consumption | 1.7 W（PUMP） |
| EAN | 6933412765295 |
| P/N | R-CL6600-BKNNA0-G-1 |
SPLIT FOR PERFECT FLOW
CL6600 keeps things cooler with a modular split-chamber layout. It places the radiator in its own zone, creating separate airflow paths for heat-generating components and letting the whole system run at its best.![]()
BALANCE IN LAYERS
A raised top chamber redefines the overall silhouette while keeping space organized. Vertical grille bars at the front provide natural ventilation and create visual rhythm, with real wood adding an organic finish to the clean, modern aesthetic
