Description
Specifications | 3.5"/2.5" Universal drive brackets | 6 included, 14 positions total |
Dedicated 2.5" drive brackets | 2 trays included, 4 positions total | |
5.25” drive mounts | 1 | |
Expansion slots | 7 + 2 | |
Front ports | 1 x USB 3.1 Gen 2 Type-C, 2 x USB 3.0, 2 x USB 2.0, Audio I/O, Power button, Reset button | |
Total fan mounts | 9 x 120/140 mm | |
Front fan | 3 x 120/140 mm (2 x Dynamic X2 GP-14 included) | |
Top fan | 3 x 120/140 mm | |
Rear fan | 1 x 120/140 mm (1 x Dynamic X2 GP-14 included) | |
Bottom fan | 2 x 120/140 mm | |
Dust filters | Top, 2 x front, full length bottom | |
Fixed velcro straps | Yes | |
Cable routing grommets | Yes | |
Captive thumbscrews | HDD brackets, SSD brackets, PSU bracket | |
Left side panel | Industrial sound-damped steel or Tempered Glass | |
Right side panel | Industrial sound-damped steel | |
Compatibility | Motherboard compatibility | E-ATX (max 285 mm) / ATX / mATX / mITX |
Power supply type | ATX | |
PSU max length | 250 mm (with HDD cage installed) | |
GPU max length | Storage layout: 290 mm - Open layout: 470 mm (445 mm w/ front fan) | |
CPU cooler max height | 185 mm | |
Front radiator | Up to 360/280 mm | |
Top radiator | Up to 360/420 mm | |
Rear radiator | 120 mm | |
Bottom radiator | Up to 240/280 mm | |
Cable routing space | 30 mm | |
Vertical GPU Support (with Flex B-20 or Flex VRC-25) | 65mm total clearance, standard 2-slot GPU (<38mm thickness) recommended for optimum cooling | |
Dimensions | Case dimensions (LxWxH) | 547 x 240 x 475 mm |
Case dimensions w/o feet/protrusions/screws | 533 x 240 x 451 mm | |
Package dimensions (LxWxH) | 558 x 363 x 641 mm | |
Net weight | Solid Version: 13.49 kg, TG Version: 13.45 kg | |
Package weight | Solid Version: 15.98 kg TG Version: 15.94 kg | |
Volume | 57.7 liters | |
Other | Warranty | 2 Years |
Package contents | Define 7 case. Accessory box. User manual. Ventilated top. 4 x HDD/SSD trays (for a total of 6) | |
Define 7 Black Solid | SKU: FD-C-DEF7A-01 EAN: 7340172702191 UPC: 843276102197 JAN: 4537694275842 | |
Define 7 Black TG Light Tint | SKU: FD-C-DEF7A-02 EAN: 7340172702207 UPC: 843276102203 JAN: 4537694275859 | |
Define 7 Black TG Dark Tint | SKU: FD-C-DEF7A-03 EAN: 7340172702214 UPC: 843276102210 JAN: 4537694275866 | |
Define 7 Black/White TG Clear Tint | SKU: FD-C-DEF7A-05 EAN: 7340172702238 UPC: 843276102234 JAN: 4537694275880 | |
Define 7 White Solid | SKU: FD-C-DEF7A-09 EAN: 7340172702276 UPC: 843276102272 JAN: 4537694276184 | |
Define 7 White TG Clear Tint | SKU: FD-C-DEF7A-06 EAN: 7340172702245 UPC: 843276102241 JAN: 4537694275897 | |
Define 7 Gray Solid | SKU: FD-C-DEF7A-07 EAN: 7340172702252 UPC: 843276102258 JAN: 4537694275903 | |
Define 7 Gray TG Light Tint | SKU:FD-C-DEF7A-08 EAN: 7340172702269 UPC: 843276102265 JAN: 4537694275910 |
