Description
"
| Specifications | 3.5""/2.5"" Universal drive brackets | 6 + 2 included, 18 positions total |
| Dedicated 2.5"" drive brackets | 2 included, 5 positions total | |
| 5.25” drive mounts | 2 | |
| Expansion slots | 9 + 3 | |
| Front ports | 1 x USB 3.1 Gen 2 Type-C, 2 x USB 3.0, 2 x USB 2.0, Audio I/O, Power button, Reset button | |
| Total fan mounts | 11 x 120 mm or 9 x 140 mm | |
| Front fan | 4 x 120 mm or 3 x 140 mm, (2 x Dynamic X2 GP-14 included) | |
| Top fan | 4 x 120 mm or 3 x 140 mm | |
| Rear fan | 1 x 120/140 mm, (1 x Dynamic X2 GP-14 included) | |
| Bottom fan | 2 x 120/140 mm | |
| Dust filters | Top, 2 x Front, Bottom + PSU | |
| Fixed velcro straps | Yes | |
| Cable routing grommets | Yes | |
| Captive thumbscrews | HDD brackets, SSD brackets, PSU bracket | |
| Left side panel | Industrial sound-damped steel or Tempered Glass | |
| Right side panel | Industrial sound-damped steel | |
| Compatibility | Motherboard compatibility | E-ATX / ATX / mATX / mITX / EE-ATX / SSI-CEB / SSI-EEB |
| Power supply type | ATX | |
| PSU max length | 250 mm (both HDD cages installed) | |
| GPU max length | Storage layout: 340 mm - Open layout: 530 mm (505 mm w/ front fan) | |
| CPU cooler max height | 185 mm | |
| Front radiator | Up to 480/420 mm | |
| Top radiator | Up to 480/420 mm | |
| Rear radiator | 120 mm | |
| Bottom radiator | Up to 240/280 mm | |
| Cable routing space | 30 mm | |
| Vertical GPU Support (with Flex B-20 or Flex VRC-25) | 65mm total clearance, standard 2-slot GPU (<38mm thickness) recommended for optimum cooling | |
| Dimensions | Case dimensions (LxWxH) | 604 x 240 x 566 mm |
| Case dimensions w/o feet/protrusions/screws | 590 x 240 x 548 mm | |
| Package dimensions (LxWxH) | 646 x 357 x 708 mm | |
| Net weight | Solid Version: 16.53 kg, TG Version: 16.64 kg | |
| Package weight | Solid Version: 18.73 kg, TG Version: 18.84 kg | |
| Volume | 77.6 liters | |
| Other | Warranty | 2 Years |
| Package contents | Define 7 XL - Accessory box - User manual - Ventilated top panel - ODD bracket - ODD bay cover - 2 x HDD/SSD trays | |
| EAN | Solid: 7340172702047, TG Dark Tint: 7340172702061, TG Light Tint: 7340172702054 | |
| UPC | Solid: 843276102043 TG Dark Tint: 843276102067, TG Light Tint: 843276102050 | |
| JAN | Solid: 4537694274296 TG Dark Tint: 4537694275385, TG Light Tint: 4537694274302 | |
| Product code | Solid: FD-C-DEF7X-01, TG Dark Tint: FD-C-DEF7X-03, TG Light Tint: FD-C-DEF7X-02 |
"
