Zoom
Description
About the item
- 8 x 10/100/1000BASE-T PoE ports
- 2 x Gigabit SFP ports
- Advanced L2 switching and security features
- L2+ Static Routing
- Optional “standard mode” or “surveillance mode” management user interface
- 130W PoE budget
Specifications
| Acoustic | 0 dB |
|---|---|
| CPU Speed | 500MHz |
| Dimensions | 330 x 180 x 44 mm |
| DRAM Size | DDR3 128MB |
| FAN | Fanless |
| Flash Memory Size | 32 MB |
| Humidity | Operating: 0% - 95% RH Storage: 0% - 95% RH |
| Interfaces | 2 x SFP ports 8 x 10/100/1000BASE-T PoE ports |
| Max. Packet Forwarding Rate | 14.88 Mpps |
| Maximum Heat Dissipation | 507.23 BTU/hr (240 V) 519.51 BTU/hr (100 V) |
| Maximum Power Consumption | 152.3 W/100 V, 148.7 W/240 V (PoE on) 8.5 W/100 V, 9.4 W/240 V (PoE off) |
| MTBF | 1,274,005 hours |
| Operating Altitude | 1500 m |
| Packet Buffer Size | 4.1Mbits |
| PoE Budget | 130 W |
| Power Input | 100 to 240 V AC |
| Standby Power Consumption | 4.3 W/100V 5.2 W/240V |
| Switch Capacity | 20 Gbps |
| Temperature | Operating: -5 to 50° C (23 to 122° F) Storage -20 - 70°C |
| Weight | 1.77 kg |
