Specifications
| Specification | Details |
|---|---|
| Product Number | MFL-B2DN-183PA-R1 |
| Series | MasterFan |
| Cooler Type | Case Fan |
| Fan Size | 120 mm |
| Dimensions (L x W x H) | 120 x 120 x 25 mm / 4.7 x 4.7 x 1.0 inch |
| Fan Bearing Type | Rifle Bearing |
| Fan MTTF | 160,000 Hours |
| Fan Rated Voltage | 12 VDC |
| Fan Rated Current | 0.25A |
| Fan Safety Current | 0.37A |
| Fan Power Consumption | 3.0W |
| Fan Power Connector | 4-Pin (PWM) |
| Fan Speed | 650–1800 RPM ± 10% |
| Fan Airflow | 47.2 CFM ± 10% |
| Fan Air Pressure | 1.6 mmH₂O ± 10% |
| Fan Noise Level | 6 – 30 dBA |
| Fan Weight | 180g x 3 |
| RGB Rated Voltage | 5 VDC |
| RGB Rated Current | 0.55A |
| RGB Connector | 3-Pin |
| LED Lighting | ARGB |
| Number of LEDs | 24 pcs x 3 |
| Fan Profiles | Addressable Gen 2 RGB |
| Note | Products manufactured after 1st June 2021 are Addressable Gen 2 RGB LEDs |
| Warranty | 2 years |
