Description
Specifications
| Category | Details |
|---|---|
| CPU | LGA1700 socket: Supports Intel® 14th / 13th / 12th Gen Core™, Pentium® Gold, and Celeron® processorsL3 cache varies by CPU |
| Chipset | Intel® B760 Express Chipset |
| Memory | - Supports DDR5 up to 8000(O.C.) MT/s- 2 × DDR5 DIMM sockets, up to 128 GB (64 GB per DIMM)- Dual-channel architecture- Supports ECC/Non-ECC un-buffered DIMMs (ECC in non-ECC mode)- Supports XMP memory modules |
| Onboard Graphics | Integrated Intel® HD Graphics (depends on CPU)- 1 × D-Sub (1920×1200@60Hz)- 1 × HDMI 2.1 (4096×2160@60Hz, HDCP 2.3)- 1 × DisplayPort 1.2 (4096×2304@60Hz, HDCP 2.3)- Supports up to triple-display |
| Audio | Realtek® Audio CODECHigh Definition Audio, 2/4/5.1/7.1-channelS/PDIF Out support |
| LAN | Realtek® 2.5GbE LAN (2.5 Gbps / 1 Gbps / 100 Mbps) |
| Wireless | Intel® Wi-Fi 6E AX210- Wi-Fi a/b/g/n/ac/ax, 2.4/5/6 GHz- Bluetooth 5.3- 11ax 160 MHz |
| Expansion Slots | - 1 × PCIe 5.0 x16 (CPU, graphics card/NVMe SSD only)- 1 × PCIe 3.0 x1 (Chipset) |
| Storage | CPU: 1 × M.2 (PCIe 4.0 x4/x2, 2280)Chipset: 1 × M.2 (PCIe 4.0 x4/x2, 2280)Chipset: 4 × SATA 6Gb/sSupports RAID 0/1/5/10 (SATA) |
| USB Ports | Back Panel:- 1 × USB Type-C® (USB 3.2 Gen 1)- 3 × USB 3.2 Gen 1- 2 × USB 2.0Internal:- 1 × USB 3.2 Gen 1 header (2 ports)- 2 × USB 2.0 headers (4 ports)Total: 10 USB ports |
| Internal I/O | - 24-pin ATX main power- 8-pin ATX 12V power- 1 × CPU fan header- 3 × System fan headers- 2 × ARGB Gen2 headers- 1 × RGB LED header- 2 × M.2 slots- 4 × SATA ports- Front panel, front audio, SPDIF Out- USB 3.2 Gen1 & USB 2.0 headers- TPM header- Serial port header- Q-Flash Plus button- Reset jumper- Clear CMOS jumper |
| Back Panel I/O | - 2 × USB 2.0- 1 × PS/2 keyboard/mouse- 2 × Wi-Fi antenna connectors- 1 × D-Sub- 1 × HDMI- 1 × DisplayPort- 3 × USB 3.2 Gen 1- 1 × USB Type-C (USB 3.2 Gen 1)- 1 × RJ-45 LAN- 3 × Audio jacks |
| I/O Controller | iTE® Controller Chip |
| H/W Monitoring | Voltage, Temperature, Fan speed detection, Water cooling flow rate, Fan fail warning, Fan speed control (depends on fan) |
| BIOS | AMI UEFI BIOS, 128 Mbit flashPnP 1.0a, DMI 2.7, WfM 2.0, SMBIOS 2.7, ACPI 5.0 |
| Unique Features | GIGABYTE Control Center (GCC), Q-Flash, Q-Flash Plus, Smart Backup |
| Bundled Software | Norton® Internet Security (OEM) |
| OS Support | Windows 11 64-bit, Windows 10 64-bit |
| Form Factor | Micro ATX, 24.4 cm × 22.5 cm |
