Description
Specifications
| Essentials | |
| Product Collection | 12th Generation IntelÆ Coreô i5 Processors |
| Code Name | Products formerly Alder Lake |
| Vertical Segment | Desktop |
| Processor Number | i5-12400F |
| Status | Launched |
| Launch Date | Q1'22 |
| Lithography | Intel 7 |
| Use Conditions | PC/Client/Tablet |
| CPU Specifications | |
| Total Cores | 6 |
| # of Performance-cores | 6 |
| # of Efficient-cores | 0 |
| Total Threads | 12 |
| Max Turbo Frequency | 4.40 GHz |
| Performance-core Max Turbo Frequency | 4.40 GHz |
| Performance-core Base Frequency | 2.50 GHz |
| Cache | 18 MB IntelÆ Smart Cache |
| Total L2 Cache | 7.5 MB |
| Processor Base Power | 65 W |
| Maximum Turbo Power | 117 W |
| Supplemental Information | |
| Embedded Options Available | No |
| Memory Specifications | |
| Max Memory Size (dependent on memory type) | 128 GB |
| Memory Types | Up to DDR5 4800 MT/s Up to DDR4 3200 MT/s |
| Max # of Memory Channels | 2 |
| Max Memory Bandwidth | 76.8 GB/s |
| Expansion Options | |
| Direct Media Interface (DMI) Revision | 4 |
| Max # of DMI Lanes | 8 |
| Scalability | 1S Only |
| PCI Express Revision | 5.0 and 4.0 |
| PCI Express Configurations á | Up to 1x16+4 | 2x8+4 |
| Max # of PCI Express Lanes | 20 |
| Package Specifications | |
| Sockets Supported | FCLGA1700 |
| Max CPU Configuration | 1 |
| Thermal Solution Specification | PCG 2020C |
| TJUNCTION | 100∞C |
| Package Size | 45.0 mm x 37.5 mm |
| Advanced Technologies | |
| IntelÆ Gaussian & Neural Accelerator | 3 |
| IntelÆ Thread Director | No |
| IntelÆ Deep Learning Boost (IntelÆ DL Boost) | Yes |
| IntelÆ Optaneô Memory Supported á | Yes |
| IntelÆ Speed Shift Technology | Yes |
| IntelÆ Turbo Boost Max Technology 3.0 á | No |
| IntelÆ Turbo Boost Technology á | 2 |
| IntelÆ Hyper-Threading Technology á | Yes |
| IntelÆ 64 á | Yes |
| Instruction Set | 64-bit |
| Instruction Set Extensions | IntelÆ SSE4.1 | IntelÆ SSE4.2 | IntelÆ AVX2 |
| Idle States | Yes |
| Enhanced Intel SpeedStepÆ Technology | Yes |
| Thermal Monitoring Technologies | Yes |
| IntelÆ Volume Management Device (VMD) | Yes |
| Security & Reliability | |
| IntelÆ Standard Manageability (ISM) á | Yes |
| IntelÆ AES New Instructions | Yes |
| Secure Key | Yes |
| IntelÆ OS Guard | Yes |
| Execute Disable Bit á | Yes |
| IntelÆ Boot Guard | Yes |
| Mode-based Execute Control (MBEC) | Yes |
| IntelÆ Control-Flow Enforcement Technology | Yes |
| IntelÆ Virtualization Technology (VT-x) á | Yes |
| IntelÆ Virtualization Technology for Directed I/O (VT-d) á | Yes |
| IntelÆ VT-x with Extended Page Tables (EPT) á | Yes |
