Description
About the item
- Designed to fit flush on the corner of the iPad Pro® 11" or 12.9" with or without a case
- Easily add a HDMI™ video output, supporting resolution up to 4K at 60 Hz
- Power and charge your laptop with up to 100W Power Delivery (3.0) pass-through charging and power your connected peripherals when it’s used with a USB-C® power adapter
- Right-angled host connector for your comfort
- Includes 3 removable pads with soft rubber for secure and flexible mounting options
- SuperSpeed USB™ ports: 1 x USB-C® and 1 x USB™ Type-A with up to 5 Gbps data transfer speed
- Connect your headphone/speaker through the 3.5mm audio jack
- Direct access to SD™ & microSD™ memory cards for data storage and transfer
- Thunderbolt 3™ compatible
Specifications
| Category | Specification |
|---|---|
| Hardware | |
| Audio Supported | Yes |
| Host Connector | 1 - USB-C® Male |
| Network Interface | N/A |
| Ports | 1 - 4K HDMI™ |
| 1 - USB-C® 3.1 with Power Delivery 3.0 & Data Transfer | |
| 1 - USB™ 3.1 Type-A | |
| 1 - SD™ & microSD™ Memory Card Reader/Writer | |
| 1 - 3.5 mm Combo Audio Jack | |
| Power Source | Bus-powered |
| Video Output | 1 - HDMI™ Female |
| Warranty | 2-Year Limited |
| Performance | |
| Audio Channel | 2.1 via HDMI™ / 3.5 mm Aux |
| Compatible Networks | N/A |
| Displays Supported | 1 |
| Max Data Transfer Rate | 5 Gbps |
| Max Display Refresh Rate | 60 Hz |
| Max Display Resolution | 3840 x 2160 |
| Power | |
| Input Current | 5A |
| Input Voltage | 20V |
| Output Current | 5A |
| Output Voltage | 20V |
| Power Consumption | ≤ 450 mA |
| Power Delivery | Up to 100W via USB-C® |
| Physical Specifications | |
| Cable Length | 8.3 in (211 mm) |
| Color | Silver, Black |
| Enclosure Type | Aluminum |
| Operating Humidity | < 85% non-condensing |
| Operating Temperature | 32 to 118°F (0 to 48°C) |
| Product Depth | 0.56 in (14.2 mm) |
| Product Height | 5.33 in (135 mm) |
| Product Weight | 3.17 oz (90 g) |
| Product Width | 2 in (50.8 mm) |
| Storage Humidity | < 85% non-condensing |
| Storage Temperature | 14 to 149°F (-10 to 65°C) |
| Package Contents | |
| 1 - JCD612 USB-C™ to 4K 60Hz HDMI™ Travel Dock for iPad Pro® | |
| 1 - Quick Installation Guide |
