Description
About This Product
Add more high-speed ports to your computer with this USB-C® 3.2 Gen 1 multi-adapter, offering a 4K HDMI™ video output, two USB™ 3.2 Gen 1 Type-A ports, and SD™ / microSD™ 3.0 UHS-I card reader/writer.
Supports USB™ 3.2 Gen 1 providing up to 5Gbps data transfer speeds and charging, this multi-adapter can support your high-performance computers such as the MacBook Pro® while still being compatible with other USB-C® devices.
The USB-C® to 4K HDMI™ Multi-Port Hub combines all the essential ports into a compact and lightweight hub, making it perfect for people who are always on the move!
Features
- • Supports HDMI™ resolutions up to 4K
- • Two USB™ 3.2 Gen 1 ports provide up to 5Gbps transfer speed
- • Power delivery 3.0 provides up to 100W of pass-through charging
- • Backwards compatibility with USB 3.0 hosts and devices
- • Memory card reader/writer slots allow for external memory access up to 2 TB, supporting SD™ 3.0 UHS-I with data transfer speeds up to 104 MB/s
- • Plug-and-play, no driver installation required
System Requirements
- • Available DisplayPort™ Alt Mode over USB-C® port
- • Available USB™ power delivery over USB-C® to support upstream charging
Hardware | |
Warranty | 2 Year Limited |
Host Connector | 1 - USB-C® Male |
Video Output | 1 - HDMI™ Female |
Power Source | Bus-powered |
Network Interface | N/A |
Audio Supported | N/A |
Ports |
|
Performance | |
Maximum Display Resolution | 3840 x 2160 @ 30 Hz |
Maximum Display Refresh Rate | 1920 x 1080 @ 60 Hz |
Maximum Data Transfer Rate | 5 Gbps |
Maximum Displays Supported | 1 |
Compatible Networks | N/A |
Audio Channel | 2.1 via HDMI™ |
Power | |
Power Delivery | Up to 100W via USB-C® |
Power Consumption | ≤ 500 mA |
Physical Specifications | |
Color | Space Gray |
Enclosure Type | Aluminum, ABS Plastic |
Cable Length | 6.69 in. (170 mm) |
Product Height | 4.42 in. (112.20 mm) |
Product Width | 1.17 in. (29.80 mm) |
Product Depth | 0.41 in. (10.41 mm) |
Product Weight | 1.69 oz (48g) |
Storage Temperature | 0 to 155°F (-17 to 68°C) |
Storage Humidity | < 85% non-condensing |
Operating Temperature | 30 to 106°F (-1 to 41°C) |
Operating Humidity | < 85% non-condensing |
Special Notes
- • A 4K-capable display is required for obtaining the 3840 x 2160 resolution
- • The adapter can connect to a USB™ 3.2 Gen 1 or USB™ 3.0 port that supports DisplayPort™ Alt mode while providing up to 5Gbps transfer rates
Package Contents
- • 1 - JCD353 USB-C® to 4K HDMI™ Multi-Port Hub
- • 1 - Quick Installation Guide (QIG)
