Description
About This Product
Add more high-speed ports to your computer with this USB-C® 3.2 Gen 1 multi-adapter, offering a 4K HDMI™ video output, two USB™ 3.2 Gen 1 Type-A ports, and SD™ / microSD™ 3.0 UHS-I card reader/writer.
Supports USB™ 3.2 Gen 1 providing up to 5Gbps data transfer speeds and charging, this multi-adapter can support your high-performance computers such as the MacBook Pro® while still being compatible with other USB-C® devices.
The USB-C® to 4K HDMI™ Multi-Port Hub combines all the essential ports into a compact and lightweight hub, making it perfect for people who are always on the move!
Features
- Supports HDMI™ resolutions up to 4K
- Two USB™ 3.2 Gen 1 ports provide up to 5Gbps transfer speed
- Power delivery 3.0 provides up to 100W of pass-through charging
- Backwards compatibility with USB 3.0 hosts and devices
- Memory card reader/writer slots allow for external memory access up to 2 TB, supporting SD™ 3.0 UHS-I with data transfer speeds up to 104 MB/s
- Plug-and-play, no driver installation required
System Requirements
- Available DisplayPort™ Alt Mode over USB-C® port
- Available USB™ power delivery over USB-C® to support upstream charging
| Hardware | |
| Warranty | 2 Year Limited |
| Host Connector | 1 - USB-C® Male |
| Video Output | 1 - HDMI™ Female |
| Power Source | Bus-powered |
| Network Interface | N/A |
| Audio Supported | N/A |
| Ports |
|
| Performance | |
| Maximum Display Resolution | 3840 x 2160 @ 30 Hz |
| Maximum Display Refresh Rate | 1920 x 1080 @ 60 Hz |
| Maximum Data Transfer Rate | 5 Gbps |
| Maximum Displays Supported | 1 |
| Compatible Networks | N/A |
| Audio Channel | 2.1 via HDMI™ |
| Power | |
| Power Delivery | Up to 100W via USB-C® |
| Power Consumption | ≤ 500 mA |
| Physical Specifications | |
| Color | Space Gray |
| Enclosure Type | Aluminum, ABS Plastic |
| Cable Length | 6.69 in. (170 mm) |
| Product Height | 4.42 in. (112.20 mm) |
| Product Width | 1.17 in. (29.80 mm) |
| Product Depth | 0.41 in. (10.41 mm) |
| Product Weight | 1.69 oz (48g) |
| Storage Temperature | 0 to 155°F (-17 to 68°C) |
| Storage Humidity | < 85% non-condensing |
| Operating Temperature | 30 to 106°F (-1 to 41°C) |
| Operating Humidity | < 85% non-condensing |
Special Notes
- A 4K-capable display is required for obtaining the 3840 x 2160 resolution
- The adapter can connect to a USB™ 3.2 Gen 1 or USB™ 3.0 port that supports DisplayPort™ Alt mode while providing up to 5Gbps transfer rates
Package Contents
- 1 - JCD353 USB-C® to 4K HDMI™ Multi-Port Hub
- 1 - Quick Installation Guide (QIG)
