Description
About the item
- Supports HDMI™ resolutions up to 4K
- USB™ 3.1 Type-A port x 2, transfer rates up to 5Gbps
- USB-C® charging port supports upstream charging & power delivery 2.0
- Plug-and-play, no driver installation required
Specifications
| Category | Specification |
|---|---|
| Hardware | |
| Audio Supported | Yes |
| Host Connector | 1 - USB-C® Male |
| Network Interface | N/A |
| Ports | 2 - USB™ Type-A 3.1 Gen 2 |
| 1 - USB-C® Power Delivery 2.0 | |
| 1 - 4K HDMI™ | |
| Power Source | Bus-powered or self-powered |
| Video Output | 1 - HDMI™ Female |
| Warranty | 2 Year Limited |
| Performance | |
| Audio Channel | 2.1 via HDMI™ |
| Compatible Networks | N/A |
| Displays Supported | 1 |
| Max Data Transfer Rate | 5 Gbps |
| Max Display Refresh Rate | 30 Hz |
| Max Display Resolution | 3840 x 2160 @ 30 Hz |
| Power | |
| Power Consumption | ≤ 500 mA |
| Power Delivery | Up to 60W via USB-C® |
| Physical Specifications | |
| Cable Length | 3.94 in. (100 mm) |
| Color | Space Grey |
| Enclosure Type | Aluminum, ABS Plastic |
| Operating Humidity | < 85% non-condensing |
| Operating Temperature | 30 to 106°F (-1 to 41°C) |
| Product Depth | 0.4 in. (10 mm) |
| Product Height | 3.11 in. (79 mm) |
| Product Weight | 1.13 oz (32 g) |
| Product Width | 0.9 in. (23 mm) |
| Storage Humidity | < 85% non-condensing |
| Storage Temperature | 0 to 155°F (-17 to 68°C) |
| Package Contents | |
| 1 - JCD371 USB-C® to HDMI™ & USB™ 3.1 2-Port with Power Delivery | |
| 1 - Quick Installation Guide (QIG) |
