Description
About the item
- UVC Capture
- HDMI™ to USB-C® with 60W Power Delivery
- Power Delivery 3.0 lets you stream live without interruption
- Ultra-low latency stream through USB-C® 3.2 connection
- 3.5 mm audio jack allows you to connect headphones or speakers
- 2 x SuperSpeed USB™ 5Gbps ports to connect additional peripherals
- UVC standard - No driver installation required
- Field production made easy with its compact size
- USB-C® Hub with 4K HDMI™
- Easily add an HDMI™ video output with resolutions up to 4K @ 30 Hz
- USB-C® Power Delivery provides up to 60W pass-through charging to the connected devices
- 2 x USB™ Type-A ports provide up to 5Gbps transfer speed
- 3.5 mm audio jack allows you to connect headphones or speakers
- No driver installation required for Windows® or macOS®
Specifications
Category | Specification |
---|---|
Hardware | |
Audio Input | No |
Audio Output | 1 - 3.5 mm AUX |
Audio Switcher | No |
Host Connector | 1 - USB-C® 3.2 Female |
Ports | 1 - USB-C® PD 3.0 |
1 - HDMI™ Input | |
1 - 4K HDMI™ Output | |
1 - 3.5 mm audio jack | |
2 - USB™ Type-A (5Gbps) | |
Power Source | Bus-powered or self-powered (USB-C® PD power) |
Video Input | 1 - HDMI™ Female |
Video Output | 1 - HDMI™ Female |
Video Switcher | No |
Warranty | 2 Year Limited |
Performance | |
Audio Channel | 2.1 via HDMI™ |
Compressions | USB™ 2.0: MJPEG |
Encode Format | MJPEG |
HDR Supported | No |
Headset | 2.1 Stereo |
Max Display Refresh Rate | 30 Hz |
Max Display Resolution | HDMI™ In: 3840 x 2160 |
USB-C® Display: 3840 x 2160 | |
Capture/Record: 1920 x 1080 | |
Microphone | N/A |
Power | |
Input Current | 3A |
Input Voltage | 20V |
Output Current | 3A |
Output Voltage | 20V |
Power Consumption | ≤ 450 mA |
Power Delivery | Up to 60W via USB-C® |
Physical Specifications | |
Cable Length | 11.8 in. (30 cm) |
Color | Black |
Enclosure Type | Plastic |
Operating Humidity | < 80% non-condensing |
Operating Temperature | 32 to 104°F (0 to 40°C) |
Product Depth | 3.79 in. (96.5 mm) |
Product Height | 0.59 in. (15 mm) |
Product Weight | 2.43 oz (69 g) |
Product Width | 1.98 in. (50.5 mm) |
Storage Humidity | < 85% non-condensing |
Storage Temperature | 14 to 149°F (-10 to 65°C) |
Package Contents | |
1 - JVA01 Video Capture USB™ Hub | |
1 - Quick Installation Guide (QIG) |
