Description
-
About This Product
- • USB Type-C™ portable dock with built-in power supply 45W
- • Supports HDMI™ output resolution 4K @ 30 Hz
- • Memory card compatible
- • Supports USB Type-C™ upstream charging, power delivery 2.0 (maximum 35W)
- • USB™ 3.1 Gen-1 data transfer up to 5 Gbps
- • 2x USB™ ports support BC1.2 (max 1.5A) in AC mode
This USB Type-C™ Power Dock is an accessory that works with Windows®, macOS® X and Android™ OS, featuring a USB™ Hub that offers Power Delivery charging, HDMI™video output, memory card reader and 2x USB™ Type-A ports. It also offers USB™ 3.1 Gen-1 SuperSpeed data link to your USB-C™ laptop for on-the-go convenience. The USB-C™ Hub with 45W power adapter has an embedded Power Delivery 2.0 charger, which can supply up to 35W PD to charge a USB-C™ PD charging device.
USB Type-C™ 3.1 Powered Mini Docking station gives you the flexibility of having 5 devices in 1:
AC Adapter
AC USB™ Wall Charger
USB™ 3.1 Gen1 Hub
HDMI™ port
USB™ to Memory Card ReaderFunctions
HDMI™ output
HDMI™ 1.4 Resolution:
1080P @ 60 Hz or 4K x 2K @ 30 HzUSB Type-C™ (Gen1)
- Compliant with USB™ 3.1 specifications Gen 1 (up to 5 Gbps)
- Supports USB Type-C™ upstream charging, Power Delivery 2.0 maximum 35W
Memory card reader
- Supports memory capacity up to 2 TB
USB™ Type-A Port-1 & Port-2 USB™ 3.1 (Gen1)
- • USB™ 2.0 & USB™ 3.1 Gen1 (up to 5 Gbps) for data transfer
- • USB™ port supports BC1.2 (max 1.5A) in AC mode; 0.5A in Hub mode
Input AC Power
100/240V AC
Physical Specifications
Case Material
ABS
Color
White
Dimensions
Main Body:
61.5 (W) x 40 (H) x 60 (D) mm
Cable Length:
30 cm (USB Type-C™ to USB Type-C™ cable)
5 in./150 cm (Power Cable)Weight
Approximately: 139g
Environmental
Storage Temperature
-20-65°C
Storage Humidity
5-90% RH. Non-condensing
Operation Temperature
0-35°C
Operation Humidity
20-85% RH. Non-condensing
System Requirements
- Available DisplayPort™ Alt Mode over USB Type-C™ port
- USB™ PD 2.0 compatible for upstream charging
Notes
- Designed for laptops that require 35W or less power charging
Package Contents
- USB Type-C™ 3.1 Powered Mini Docking Station
- USB Type-C™ to USB Type-C™ cable (30 cm)
- 5 ft / 150 cm Detachable Power Cord
