Description
| Specifications | 3.5"/2.5" Universal drive mounts | 2 (included) |
| Dedicated 2.5" drive mounts | 4 (2 included) | |
| Expansion slots | 7 | |
| Front interface | 1x USB 3.1 Gen 2 Type-C, 2x USB 3.0, Audio I/O, Power button, Reset button | |
| Total fan mounts | 7x 120 or 4x 140 mm and 2x 120 mm | |
| Front fan | 3x 120 or 2x 140 mm, (2x Dynamic X2 GP-14 included) | |
| Top fan | 2x 120/140 mm | |
| Rear fan | 1x 120 mm, (1x Dynamic X2 GP-12 included) | |
| Bottom fan | 1x 120 mm (requires removal of HDD cage) | |
| Dust filters | Top, front and bottom | |
| Fixed velcro straps | Yes | |
| Cable routing grommets | Yes | |
| Captive thumbscrews | HDD, SSD and PSU brackets | |
| Left side panel | Steel | |
| Right side panel | Steel | |
| Compatibility | Motherboard compatibility | ATX / mATX / Mini-ITX |
| Power supply type | ATX | |
| PSU max length | 200 mm (165 mm with HDD cage and front fan) | |
| GPU max length | 341 mm (360 mm without front fan) | |
| CPU cooler max height | 169 mm | |
| Front radiator | Up to 360/280 mm | |
| Top radiator | Up to 240 mm | |
| Rear radiator | 120 mm | |
| Bottom radiator | 120 mm (requires removal of HDD cage) | |
| Cable routing space | 17-28 mm | |
| Radiator Support – Additional Details | Maximum radiator width: 145mm for front mounting. Maximum motherboard component height for top mounted radiator: 40 mm. For more details, consult the manual. | |
| Dimensions | Case dimensions (LxWxH) | 424 x 210 x 475 mm |
| Case dimensions w/o feet/protrusions/screws | 412 x 210 x 455 mm | |
| Package dimensions (LxWxH) | 542 x 320 x 554 mm | |
| Net weight | Solid: 7.7 kg TG: 8.1 kg | |
| Gross weight | Solid: 9.3 kg TG: 9.8 kg | |
| Volume | 39.4 Liters | |
| Other | Warranty | 2 Years |
| Package contents | Meshify 2 Compact Case, User manual, Accessory box | |
| Meshify 2 Compact Black Solid | SKU: FD-C-MES2C-01, EAN: 7340172702320, UPC: 843276102326, JAN: 4537694276801 | |
| Meshify 2 Compact Black TG Dark Tint | SKU: FD-C-MES2C-02, EAN: 7340172702337, UPC: 843276102333, JAN: 4537694276818 | |
| Meshify 2 Compact Black TG Light Tint | SKU: FD-C-MES2C-03, EAN: 7340172702344, UPC: 843276102340, JAN: 4537694276825 | |
| Meshify 2 Compact Gray TG Light Tint | SKU: FD-C-MES2C-04, EAN: 7340172702351, UPC: 843276102357, JAN: 4537694276832 | |
| Meshify 2 Compact White TG Clear Tint | SKU: FD-C-MES2C-05, EAN: 7340172702368, UPC: 843276102364, JAN: 4537694276849 |
