Description
Specifications
| Specification | Details |
|---|---|
| Chipset | INTEL B860 |
| CPU | Supports Intel Core Ultra Processors (Series 2), LGA 1851 |
| Memory | 4x DDR5 UDIMM, Maximum 256GB Memory Support 8800 - 6400 (OC) MT/s / 6400 - 4800 (JEDEC) MT/s Max Overclocking Frequency: 1DPC 1R: up to 8800+ MT/s 1DPC 2R: up to 7200+ MT/s 2DPC 1R: up to 6400+ MT/s 2DPC 2R: up to 5600+ MT/s Supports Intel POR & JEDEC Speed, Memory OC, Intel XMP 3.0 Supports Dual-Controller Dual-Channel mode Supports Non-ECC, Un-buffered, CUDIMM The DIMM slots only have single-sided latches. Memory compatibility depends on CPU & configuration. |
| Onboard Graphics | 1x HDMI (HDMI 2.1, 4K 60Hz) 1x DisplayPort (DP 1.4, 4K 60Hz) 1x Type-C (Thunderbolt 4 DP 2.1, up to 4K@120Hz / 8K@60Hz) Available only with processors featuring integrated graphics. |
| Expansion Slots | 4x PCI-E x16 PCI_E1: Gen 5.0 x16 (CPU) PCI_E2: Gen 4.0 x1 (Chipset) PCI_E3: Gen 4.0 x1 (Chipset) PCI_E4: Gen 4.0 x4 (Chipset) |
| Audio | Realtek ALC897 Codec 7.1-Channel HD Audio |
| Storage | 3x M.2: M.2_1 (CPU) PCIe 5.0 x4 2280/2260/2242 M.2_2 (Chipset) PCIe 4.0 x4 2280/2260 M.2_3 (Chipset) PCIe 4.0 x2 2280 4x SATA 6G Refer to manual for M.2 heatsink limitations. |
| RAID | Supports RAID 0, 1, 5, 10 for SATA storage |
| Onboard Thunderbolt | 1x Thunderbolt 4 (rear) 40Gbps with TB devices, 20Gbps with USB4, 10Gbps USB 3.2 Supports 5V/3A (15W) charging Daisy-chain up to 3 TB4 or 5 TB3 devices Supports up to 8K display |
| USB | Rear: 2x USB 2.0 2x USB 5Gbps Type-A 1x USB 5Gbps Type-C 1x USB 10Gbps Type-A Front: 4x USB 2.0 4x USB 5Gbps Type-A 1x USB 10Gbps Type-C |
| LAN | Realtek 8126 5Gbps LAN |
| Internal I/O | 1x Thunderbolt5 card connector ATX_PWR, CPU_PWR x2, PCIE_PWR (8-pin) CPU Fan, Pump/Sys Fan, 3x Sys Fan Front Panel x2 Chassis Intrusion Front Audio COM Port Tuning Controller (JDASH) ARGB V2 x2, RGB x1 TPM 2.0 Header USB 2.0 x4 USB 5Gbps x4 USB 10Gbps Type-C x1 |
| Wireless LAN & Bluetooth | Intel Wi-Fi 7 (M.2 Key-E module) 2.4/5/6GHz (320MHz), up to 5.8Gbps 802.11 a/b/g/n/ac/ax/be Bluetooth 5.4, MLO, 4KQAM |
| LED Features | 4x EZ Debug LED 1x EZ Memory Detection LED |
| Back Panel Ports | DisplayPort Keyboard/Mouse USB 5Gbps Type-A 5G LAN Wi-Fi/Bluetooth Audio Ports HDMI Thunderbolt 4 (Type-C) USB 2.0 Clear CMOS Button USB 10Gbps Type-A USB 5Gbps Type-C |
| Operating System | Windows 11 64-bit Support |
