Specifications:
| Category | Details |
|---|---|
| Print Method | Serial Impact Dot Matrix |
| Number of Pins in Head | 9 pins |
| Print Direction | Bi-directional |
| Control Code | ESC / P, IBM Proprinter |
| Print Width | 80 Column |
| Print Head Life | 200 Plus Million Characters |
| Print Speed (High Speed Draft) | 10 / 12 / 15 cpi 350/360/400 cps |
| Print Speed (Draft) | 10 / 12 / 15 cpi 270 / 320 / 375 cps |
| Print Speed (NLQ) | 10 / 12 / 15 65 /75 /75 cps |
| Character Sets (Resident Printer Font) | Draft, Near Letter Quality |
| Resident Barcode Fonts | Code 3 of 9 |
| Printable Columns (Pitch) | 10 / 12 / 15 / 17 / 20 cpi |
| Printable Columns (Width) | 80 / 96 / 120 / 137 / 160 cpl |
| Paper Handling (Paper Path) | Tractor / Manual (Top, rear, bottom), Continuous Tractor, Convertible push and pull |
| Paper Handling (Cut Sheet) | 3.5 - 10" |
| Paper Handling (Paper Thickness) | 0.3 mm |
| Paper Handling (Continuous Paper) | 3.5 - 10" |
| Paper Handling (Roll Paper) | Yes |
| Paper Feeding (Standard) | Friction, Push Tractor |
| Copies | 1+3 with carbon |
| Line Spacing | 4.23mm (1/6") or programmable in increments of 0.118mm (1/216") |
| Input Data Buffer | 100 KB |
| Interface | Bi-directional parallel (IEEE-1284), USB 2.0 Full-Speed, Serial (Optional) |
| Ribbon Cartridge | Patented TVS-E ribbon cassette with user replaceable ink bank |
| Reliability (MTBF) | 15,000 POH |
| Acoustics | 55 dB (A) in ISO 7779 Sonic Pattern |
| Emulation | EPSON ESC/P, IBM Proprinter |
| Control Panel | 4 switches and 5 LEDs |
| Environmental Conditions (Operating) | Temperature: (+5°C to +45°C), Humidity: 10% to 80% |
| Electrical Specification | Rated Voltage: 90V – 270V AC, Rated Frequency: 47 - 63 Hz, Power Consumption (Operating): 34W, Self Test: 12W |
| Printer Driver / Utility | Operating System: Windows 9X, NT 4.0, ME, 2000, 2003, XP, VISTA, Windows 7, Linux |
| Electronic Guide | HTML Based |
| Dimensions (W x D x H) | 433 x 379 x 147 mm |
| Weight | 5.7 kg |
| Warranty | 1 year |
