Description
Specifications
| Socket Compatibility | AM5, AM4, LGA1700, LGA1851, LGA1954, LGA1156, LGA1155, LGA1150, LGA1151, LGA1200 |
|---|---|
| Total Height | 142 mm |
| Fan Configuration | 1x 140×140×25 mm (square) |
| NSPR | 119 |
| Colour | Brown |
| Warranty | 6 years |
| Scope of Delivery | NF-A14 PWM premium fan NA-RC7 Low-Noise Adaptor (L.N.A.) Fan-clips for second NF-A14 NT-H1 high-grade thermal compound SecuFirm2™ mounting kit Noctua metal case-badge |
| Fan Model | NF-A14 PWM |
| Size (Form Factor) | 140 × 140 × 25 mm (square) |
| Speed Range | 0 – 1500 rpm |
| Airflow (Max) | 140.2 m³/h (82.52 CFM) |
| Acoustical Noise (Max) | 24.6 dB(A) |
| Static Pressure (Max) | 2.08 mm H?O |
| Rated Voltage | 12 V |
| Input Power | 1.19 W (typical) |
| Connector | 4-pin |
| Colour | Brown |
| Warranty | 6 years |
| Height with Fans | 142 mm |
| Height without Fans | 115 mm |
| Width with Fans | 140 mm |
| Width without Fans | 140 mm |
| Depth with Fans | 163 mm |
| Depth without Fans | 163 mm |
| Weight with Fans | 1015 g |
| Weight without Fans | 786 g |
| Material (Heatsink Base) | Copper, nickel plated |
| Material (Heatsink Fins) | Aluminium, nickel plated |
| Material (Heatpipes) | Copper, nickel plated |
| Interface Heatpipes / Fins | Soldered |
| Number of Heatpipes | 6 |
| Heatpipe Diameter | 6 mm |
| Fin Count | 66 |
| Mounting Hole Pitch | 83 mm |
| Rack Unit Compatibility | 5U, 4U |
| Base Size | 38 × 40 mm |
| NSPR | 119 |
| Packaging Dimensions | 183 × 246 × 197 mm |
| Packaging Weight | 1854 g |
| EAN | 4716123315698 |
| UPC | 842431012623 |
| Packaging Unit | 8 pcs |
| Packaging Unit Dimensions | 412 × 520 × 417 mm |
| Packaging Unit Weight | 16 kg |
