Specification | |
| Model | CM-H92FB-01 |
| Dimensions | Height: 506 mm (19.9 in) Width: 315 mm (12.4 in) Depth: 481 mm (18.9 in) Volume: 76.7 L Weight: 12.46 kg (27.47 lb) |
| General | Enclosure Type: Mid-tower Motherboard Compatibility: E-ATX (Up to 277 mm), ATX, Micro-ATX, Mini-ITX Rear-Connecting Motherboard Support (BTF, Project Zero): Yes (ATX) Materials: SGCC steel, tinted tempered glass (black) |
| Clearance | CPU Cooler Height: 165 mm GPU Length: Up to 459 mm (with <56 mm thickness fans installed at the front-right) Up to 410 mm (with 56 mm thick 420 mm AIO and fans installed at the front-right) PSU Length: 200 mm Top Radiator & Fan Thickness: Up to 80 mm (360 mm) Up to 62 mm (420 mm) |
| Front I/O Ports | USB 3.2 Type-A: 2 USB 3.2 Gen2x2 Type-C: 1 Headset Jack: 1 |
| Expansion Slots | Standard: 7 Vertical: 0 |
| Drive Bays | 2.5": 4+2 3.5": 2 |
| Fan Support | Front-Right 3 x 120 mm / 3 x 140 mm (3 x F140Q (CV) included) Top 3 x 120 mm / 3 x 140 mm Bottom 3 x 120 mm / 3 x 140 mm Rear 1 x 120 mm (1 x F120Q (CV) included) |
| Radiator Support | Front-Right: Up to 420 mm Top: Up to 420 mm Bottom: Up to 360 mm Rear: Up to 120 mm |
| Fan Specs | F140Q (CV) Model: F140Q (CV) Speed: 1,350 ± 150 RPM Airflow: 100.25 CFM Static Pressure: 1.4 mmH2O Noise: 22.9 dBA Fan Connector: 3-pin F120Q (CV) Model: F120Q (CV) Speed: 1,350 ± 150 RPM Airflow: 60.2 CFM Static Pressure: 1.05 mmH2O Noise: 24.1 dBA Fan Connector: 3-pin |
| Warranty | 2 years |
