Description
About the item:
- GPU: Boost Clock: Up to 3320 MHz
- GPU: Game Clock: Up to 2780 MHz
- Memory: 16GB/128 bit DDR6. 20 Gbps Effective
- Stream Processors: 2048
- AMD RDNA™ 4 Architecture
- Ray Accelerator: 32
Specifications
| Category | Specification |
|---|---|
| GPU Model | AMD Radeon™ RX 9060 XT |
| Architecture | AMD RDNA™ 4 |
| Compute Units | 32 CUs (3rd Gen RT + 2nd Gen AI Accelerators) |
| Stream Processors | 2048 |
| Ray Accelerators | 32 |
| AI Accelerators | 64 |
| Engine Clock | Boost Clock: Up to 3320 MHzGame Clock: Up to 2780 MHz |
| Memory | 16GB GDDR6 |
| Memory Bus | 128-bit |
| Memory Clock | 20 Gbps Effective |
| Infinity Cache | 32MB |
| Max Display Support | 3 Displays |
| Maximum Resolution | HDMI®: 7680×4320DisplayPort™ 2.1a: 7680×4320 |
| Display Outputs | 2x HDMI®, 1x DisplayPort™ 2.1a |
| Interface | PCI-Express 5.0 x16 |
| Form Factor | ATX, 2.7 Slot |
| Dimensions | 300mm (L) x 131mm (W) x 55mm (H) |
| Power Consumption | 182W Typical Board Power |
| Power Connector | 1 x 8-pin |
| Recommended PSU | Minimum 450W |
| Operating Systems | Linux®, Windows® 10, Windows® 11 (64-bit required) |
| Game Index | 1440P Gaming |
Sapphire Features
-
Honeywell PTM7950 TIM
-
AeroCurve Fan Blade
-
Free Flow / FrameDefense
-
Tri-X Cooling Technology
-
Integrated Cooling Module
-
High TG Copper PCB
-
Optimized Composite Heatpipes
-
Metal Backplate
-
ARGB Light Bar
-
Fan Quick Connect
-
Two-Ball Bearing Fans
-
Premium 9-Phase Digital Power
-
Fuse Protection
-
Intelligent & Precision Fan Control
-
TriXX Supported (Fan Check, Glow!, TriXX Boost, RGB Sync, etc.)
AMD Features
-
AMD HYPR-RX with AFMF 2
-
FidelityFX™ Super Resolution 4 (AI Upscaling)
-
AMD Fluid Motion Frames 2
-
Radeon™ Anti-Lag 2
-
DisplayPort™ 2.1a
-
Radiance Display™ Engine
-
AV1 Encode/Decode
-
AMD Noise Suppression
-
AMD Freesync™
-
Smart Technologies
-
Microsoft® DirectX® 12 Ultimate
-
AMD Software: Adrenalin Edition™
Bundled Accessories
-
L-Shape Support Bracket
-
3-pin 5V ARGB Cable
