Zoom
Description
About this item
- Dimensions (L x W x H) 26" x 10.24" x 24.65"
- USB 3.0 x 2, USB 2.0 x 2, HD Audio x 1, Type-C x 1
- Three 4mm thick tempered glass panels protect the chassis while providing easy access to the components
- AIO Capable up to 480mm radiator at the front and 360mm radiator on the top
- 3-year warranty
Specifications
| P/N | CA-1Q2-00M1WN-00 |
| SERIES | Core |
| MODEL | Core P8 TG |
| CASE TYPE | Full Tower |
| DIMENSION (H X W X D) | 660 x 260 x 626 mm |
| (26 x 10.24 x 24.65 inch) | |
| NET WEIGHT | 22.6 kg / 49.8 lbs |
| SIDE PANEL | Tempered Glass x 3 (4mm thickness) |
| COLOR | Black |
| MATERIAL | SPCC |
| DRIVE BAYS | |
| -ACCESSIBLE | 1 x 2.5íí (with Pump Bracket) |
| -HIDDEN | 3 x 3.5íí or 6 x 2.5íí (With HDD Bracket) |
| EXPANSION SLOTS | 8 |
| MOTHERBOARDS | 6.7î x 6.7î (Mini ITX), 9.6î x 9.6î (Micro ATX), |
| 12î x 9.6î (ATX), 12î x 13î(E-ATX) | |
| I/O PORT | 1 x USB 3.1 (Gen 2) Type C, 2 x USB 3.0, x 2 USB 2.0, 1 x HD Audio |
| PSU | Standard PS2 PSU (optional) |
| FAN SUPPORT | Front: 4 x 120mm or 3 x 120mm or 2 x 120mm or 1 x 120mm |
| 3 x 140mm or 2 x 140mm or 1 x 140mm | |
| Top: 4 x 120mm or 3 x 120mm or 2 x 120mm or 1 x 120mm | |
| 3 x 140mm or 2 x 140mm or 1 x 140mm | |
| Rear: 1 x 120mm or 2 x 120mm , | |
| Right: 4 x 120mm or 3 x 120mm or 2 x 120mm or 1 x 120mm | |
| 3 x 140mm or 2 x 140mm or 1 x 140mm | |
| Bottom: 4 x 120mm or 3 x 120mm or 2 x 120mm or 1 x 120mm | |
| 3 x 140mm or 2 x 140mm or 1 x 140mm | |
| RADIATOR SUPPORT | Front: 1 x 480mm or 1 x 360mm or 1 x 240mm or 1 x 120mm |
| 1 x 420mm or 1 x 280mm or 1 x 140mm | |
| Top: 1 x 360mm or 1 x 240mm or 1 x 120mm | |
| 1 x 280mm or 1 x 140mm | |
| Right: 1 x 480mm or 1 x 360mm or 1 x 240mm or 1 x 120mm | |
| 1 x 420mm or 1 x 280mm or 1 x 140mm | |
| Bottom: 1 x 240mm or 1 x 120mm (With P5 DP-D5 ) , | |
| CLEARANCE | CPU cooler height limitation: 180mm |
| VGA length limitation: 280mm (With Reservoir) | |
| 320mm (Without Reservoir) | |
| PSU length limitation: 200mm |
