Description
| Description | |
| P/N | CA-1T9-00M1WN-01 |
| MODEL | H570 TG ARGB |
| CASE TYPE | Mid Tower |
| DIMENSION (H X W X D) | 487 x 216 x 463.6 mm |
| (19.2 x 8.5 x 18.3 inch) | |
| NET WEIGHT | 7.5 kg / 16.5 lbs. |
| PANEL | 4mm Tempered Glass x 1 |
| COLOR | Black |
| MATERIAL | SPCC |
| COOLING SYSTEM | Front(intake): |
| 120 x 120 x 25 mm ARGB Lite fan (1000rpm, 22.3 dBA) x 3 | |
| DRIVE BAYS | 2 x 3.5”, 2 x 2.5” or 4 x 2.5” |
| EXPANSION SLOTS | 7 |
| MOTHERBOARDS | 6.7” x 6.7” (Mini ITX), 9.6” x 9.6” (Micro ATX), |
| 12” x 9.6” (ATX), 12” x 13”(E-ATX) | |
| I/O PORT | USB 3.0 x 2, HD Audio x 1 |
| PSU | Standard PS2 PSU (optional) |
| FAN SUPPORT | Front: |
| 3 x 120mm, 2 x 120mm, 1 x 120mm | |
| 3 x 140mm, 2 x 140mm, 1 x 140mm | |
| 2 x 200mm, 1 x 200mm | |
| Top: | |
| 3 x 120mm, 2 x 120mm, 1 x 120mm, | |
| 2 x 140mm, 1 x 140mm | |
| Rear: | |
| 1 x 120mm | |
| RADIATOR SUPPORT | Front: |
| 1 x 360mm, 1 x 240mm, 1 x 120mm | |
| 1 x 280mm, 1 x 140mm | |
| Top: | |
| 1 x 360mm, 1 x 240mm, 1 x 120mm | |
| 1 x 280mm, 1 x 140mm | |
| Rear: | |
| 1 x 120mm | |
| CLEARANCE | CPU cooler height limitation: |
| 160mm | |
| VGA length limitation: | |
| 375mm | |
| PSU length limitation: | |
| 180mm | |
