Description
Features:
- Line-interactive UPS Topology
- Simulated Sine Wave Output
- Overload Protection
- LED Status Indicato
- Automatic Voltage Regulation (AVR)
- Generator Compatible
- EMI and RFI Filtration
- Configurable Alarm
Desktop UPS Specifications:
| Category | Specifications |
|---|---|
| General | |
| Phase | Single Phase |
| Form Factor | Desktop |
| UPS Topology | Line-interactive |
| Input | |
| Generator Compatibility | Yes |
| Nominal Input Voltage | 230 ± 10% Vac |
| Input Voltage Range | 140 ~ 300 Vac |
| Input Frequency | 50 ± 10 Hz, 60 ± 10 Hz |
| Input Frequency Detection | Auto-sensing |
| Rated Input Current | 4.55 A |
| Input Connector Type | IN/ZA |
| Power Cord Length | 4 ft (1.2 m) |
| Output | |
| Capacity (VA) | 1000 |
| Capacity (Watts) | 600 |
| On Battery Waveform | Simulated Sine Wave |
| On Battery Voltage | 230 ± 10% Vac |
| On Battery Frequency | 50 ± 1% Hz, 60 ± 1% Hz |
| Automatic Voltage Regulation (AVR) | Double Boost, Single Buck |
| Overload Protection | Circuit Breaker |
| Outlet(s) - Total | 4 |
| Outlet Type | IN/ZA x 4 |
| Outlet(s) - Battery Backup | 4 |
| Typical Transfer Time | 4 ms |
| Battery | |
| Runtime at 60W | 60 min |
| Runtime at 90W | 45 min |
| Runtime at 200W | 14 min |
| Typical Recharge Time | 8 hours |
| Start On Battery | Yes |
| User-replaceable | No |
| Battery Type | Sealed Lead-acid |
| Surge Protection & Filtering | |
| EMI/RFI Filtration | Yes |
| Management & Communications | |
| LED Indicators | Power On, Line Mode, Battery Mode, Low Battery |
| Audible Alarms | Battery Mode, Low Battery, Overload, UPS Fault |
| Physical | |
| Enclosure Construction | Plastic |
| Color | Black |
| Physical Size (WxHxD) | 190 x 110.5 x 290 mm (7.48 x 4.35 x 11.42 in) |
| Weight | 6.9 kg (15.21 lbs) |
| Shipping Dimensions | 161 x 265 x 338 mm (6.3 x 10.4 x 13.3 in) |
| Shipping Weight | 7.12 kg (15.7 lbs) |
| Environmental | |
| Operating Temperature | 0 ~ 40°C (32 ~ 104°F) |
| Storage Temperature | -20 ~ 50°C (-4 ~ 122°F) |
| Operating Relative Humidity | 0 ~ 90% (non-condensing) |
| Storage Relative Humidity | 0 ~ 90% (non-condensing) |
| Operating Elevation | 0-9,843 ft (0-3,000 m) |
| Online Thermal Dissipation | 45 BTU/hr |
| Certifications | |
| Certifications | BIS, RoHS |
| Warranty | |
| Product Warranty | 2 years |
| Battery Warranty | 1 year |
