Description
Features:
- Line-interactive UPS Topology
- Automatic Voltage Regulation (AVR)
- LED Status Indicator
- Surge and Spike Protection
- High-speed Ethernet Data Transmission
- PowerPanel Management Software
- EMI and RFI Filtration
- Energy Saving Technology
- Generator Compatible
- Overload Protection
- Phone/Fax/Modem/DSL/Network Protection
- USB Connectivity Port
- Configurable Alarm
Tower UPS Specifications:
| Category | Specifications |
|---|---|
| General | |
| Phase | Single Phase |
| Form Factor | Tower |
| UPS Topology | Line-interactive |
| Energy Saving Technology | GreenPower UPS™ Bypass Technology |
| Input | |
| Generator Compatibility | Yes |
| Nominal Input Voltage | 230 ± 10% Vac |
| Input Voltage Range | 167 ~ 295 Vac |
| Input Frequency | 50 Hz, 60 Hz |
| Input Frequency Detection | Auto-sensing |
| Rated Input Current | 10 A |
| Input Connector Type | IN/ZA |
| Power Cord Length | 5 ft (1.5 m) |
| Output | |
| Capacity (VA) | 2200 |
| Capacity (Watts) | 1320 |
| On Battery Waveform | Simulated Sine Wave |
| On Battery Voltage | 230 ± 10% Vac |
| On Battery Frequency | 50 ± 1% Hz, 60 ± 1% Hz |
| Automatic Voltage Regulation (AVR) | Single Boost, Single Buck |
| Overload Protection | Internal Current Limiting, Circuit Breaker |
| Outlet(s) - Total | 4 |
| Outlet Type | IN/ZA x 4 |
| Outlet(s) - Battery & Surge Protected | 4 |
| Typical Transfer Time | 4 ms |
| Battery | |
| Runtime at 60W | 95 min |
| Runtime at 90W | 70 min |
| Runtime at 200W | 34 min |
| Typical Recharge Time | 8 hours |
| Start On Battery | Yes |
| User-replaceable | No |
| Battery Type | Sealed Lead-acid |
| Surge Protection & Filtering | |
| Surge Suppression (Joules) | 150 |
| EMI/RFI Filtration | Yes |
| Phone/Network Protection (RJ11/RJ45 Combo) | 1-in, 1-out |
| Management & Communications | |
| LED Indicators | Power On, Line Mode, Battery Mode, Bypass Mode, Low Battery, Overload, UPS Fault |
| HID Compliant USB Port(s) | 1 |
| Audible Alarms | Battery Mode, Low Battery, Overload, UPS Fault |
| Management Cable | USB Cable x1 |
| Ethernet Data Speed | Up to 1 Gbps |
| Power Management Software | PowerPanel Personal (Recommended) |
| Physical | |
| Enclosure Construction | Plastic |
| Color | Black |
| Physical Size (WxHxD) | 148 x 178 x 298 mm (5.83 x 7.01 x 11.73 in) |
| Weight | 10.8 kg (23.81 lbs) |
| Shipping Dimensions | 271 x 202 x 397 mm (10.67 x 7.95 x 15.63 in) |
| Shipping Weight | 11.1 kg (24.47 lbs) |
| Environmental | |
| Operating Temperature | 0 ~ 40°C (32 ~ 104°F) |
| Storage Temperature | -20 ~ 50°C (-4 ~ 122°F) |
| Operating Relative Humidity | 0 ~ 90% (non-condensing) |
| Storage Relative Humidity | 0 ~ 90% (non-condensing) |
| Operating Elevation | 0-9,843 ft (0-3,000 m) |
| Storage Elevation | 0-9,843 ft (0-3,000 m) |
| Online Thermal Dissipation | 34.1 BTU/hr |
| Audible Noise (1.5M) | 50 dBA |
| Certifications | |
| Certifications | BIS, RoHS |
