| Description | |
| Display Size (in.): | 22 |
| Viewable Area (in.): | 21.5 |
| Panel Type: | IPS Technology |
| Resolution: | 1920 x 1080 |
| Resolution Type: | FHD (Full HD) |
| Static Contrast Ratio: | 1,000:1 (typ) |
| Dynamic Contrast Ratio: | 50M:1 |
| Light Source: | LED |
| Brightness: | 200 cd/m² (typ) |
| Colors: | 16.7M |
| Color Space Support: | 8 bit (6 bit + Hi-FRC) |
| Aspect Ratio: | 16:09 |
| Response Time (Typical GTG): | 5ms |
| Response Time (GTG w/OD): | 5ms |
| Viewing Angles: | 178º horizontal, 178º vertical |
| Backlight Life (Hours): | 30000 Hrs (Min) |
| Curvature: | Flat |
| Refresh Rate (Hz): | 60 |
| Low Blue Light: | Software solution |
| Flicker-Free: | Yes |
| Color Gamut: | NTSC: 77% size (Typ) sRGB: 108% size (Typ) |
| Pixel Pitch: | 0.248 mm (H) x 0.248 mm (V) |
| Touch Screen: | Projected Capacitive, 10-point multi-touch |
| Surface Treatment: | Glossy, Hard Coating (7H) |
| Cover Glass Thickness: | 0.7mm |
| COMPATIBILITY | |
| PC Resolution (max): | 1920x1080 |
| Mac® Resolution (max): | 1920x1080 |
| PC Operating System: | Windows 7/8/8.1/10/11 certified; macOS tested |
| Mac® Resolution (min): | 1920x1080 |
| CONNECTOR | |
| VGA: | 1 |
| USB 3.2 Type A Down Stream: | 2 |
| USB 3.2 Type B Up Stream: | 1 |
| 3.5mm Audio In: | 1 |
| 3.5mm Audio Out: | 1 |
| HDMI 1.4: | 1 |
| DisplayPort: | 1 |
| Power in: | DC Socket (Center Positive) |
| AUDIO | |
| Internal Speakers: | 3Watts x2 |
| POWER | |
| Eco Mode (Conserve): | 16 w/ ES 7.0; 19 w/o ES 7.0W |
| Eco Mode (optimized): | 18 w/ ES 7.0; 22 w/o ES 7.0W |
| Consumption (typical): | 20 w/ ES 7.0; 25 w/o ES 7.0W |
| Consumption (max): | 25 w/ ES 7.0; 28 w/o ES 7.0W |
| Voltage: | AC 100-240V |
| Stand-by: | 0.5W |
| Power Supply: | External Power Adaptor |
| ADDITIONAL HARDWARE | |
| Kensington Lock Slot: | 1 |
| CONTROLS | |
| Physical Controls: | 1, 2, Up, Down, Power |
| On Screen Display: | Auto Image Adjust, Contrast/Brightness, Input Select, Audio Adjust, Color Adjust, Information, Manual Image Adjust, Setup Menu, Memory Recall |
| OPERATING CONDITIONS | |
| Temperature: | 32°F to 104°F (0°C to 40°C) |
| Humidity (non-condensing): | 20% to 90% |
| WALL MOUNT | |
| VESA Compatible: | 100 x 100 mm |
| INPUT SIGNAL | |
| Frequency Horizontal: | RGB Analog: 24 ~ 82KHz, HDMI (v1.4): 15 ~ 82KHz, DisplayPort (v1.2): 15 ~ 82KHz |
| Frequency Vertical: | RGB Analog: 50 ~ 76Hz, HDMI (v1.4): 50 ~ 76Hz, DisplayPort (v1.2): 50 ~ 76Hz |
| VIDEO INPUT | |
| Digital Sync: | TMDS - HDMI (v1.4), PCI-E - DisplayPort (v1.2) |
| Analog Sync: | Separate/Composite/SOG - RGB Analog |
| ERGONOMICS | |
| Tilt (Forward/Back): | 20º / 70º |
| WEIGHT (IMPERIAL) | |
| Net (lbs): | 7.9 |
| Net Without Stand (lbs): | 7.9 |
| Gross (lbs): | 10.4 |
| WEIGHT (METRIC) | |
| Net (kg): | 3.6 |
| Net Without Stand (kg): | 3.6 |
| Gross (kg): | 4.7 |
| DIMENSIONS (IMPERIAL) (WXHXD) | |
| Packaging (in.): | 21.7 x 14.6 x 4.5 |
| Physical (in.): | 19.3 x 11.8 x 1.9 |
| Physical Without Stand (in.): | 19.3 x 11.8 x 1.9 |
| DIMENSIONS (METRIC) (WXHXD) | |
| Packaging (mm): | 550 x 371 x 114 |
| Physical (mm): | 490 x 299 x 47 |
| Physical Without Stand (mm): | 490 x 299 x 47 |
| GENERAL | |
| Regulations: | cTUVus, FCC-B, ICES003, Energy Star, EPEAT, CEC, MX-CoC, Mexico Energy, CE, CE EMC, CB, RoHS, ErP, REACH, WEEE, EAC, UkrSEPRO, BIS, CCC, China RoHS, China Energy Label, CECP |
| PACKAGE CONTENTS: | TD2230 x1, 3-pin Mickey Mouse Plug (IEC C5) x1, HDMI Cable (v1.4; Male-Male) x1, USB A/B Cable (v3.2; Male-Male) x1, Audio Cable (Male-Male) x1, AC/DC Adapter x1, Quick Start Guide x1 |
| Recycle/Disposal: | Please dispose of in accordance with local, state or federal laws. |
| Warranty: | *Warranty offered may differ from market to market |
| Power Management: | Energy Star standards, EPEAT |
