Zoom
Description
| Description | |
| Display Size (in.): | 24 |
| Viewable Area (in.): | 23.6 |
| Panel Type: | VA Technology |
| Resolution: | 1920 x 1080 |
| Resolution Type: | FHD (Full HD) |
| Static Contrast Ratio: | 3,000:1 (typ) |
| Dynamic Contrast Ratio: | 20M:1 |
| Light Source: | LED |
| Brightness: | 250 cd/m² (typ) |
| Colors: | 16.7M |
| Color Space Support: | 8 bit (6 bit + Hi-FRC) |
| Aspect Ratio: | 16:09 |
| Response Time (Typical GTG): | 7ms |
| Response Time (GTG w/OD): | 7ms |
| Response Time (Typical Tr+Tf): | 25ms |
| Viewing Angles: | 178º horizontal, 178º vertical |
| Backlight Life (Hours): | 40000 Hrs (Min) |
| Curvature: | Flat |
| Refresh Rate (Hz): | 75 |
| Low Blue Light: | Software solution |
| Flicker-Free: | Yes |
| Color Gamut: | NTSC: 72% size (Typ) sRGB: 104% size (Typ) |
| Pixel Pitch: | 0.272 mm (H) x 0.272 mm (V) |
| Touch Screen: | IR, 10-point multi-touch |
| Surface Treatment: | Glossy, Hard Coating (7H) |
| Cover Glass Thickness: | 1.85mm |
| COMPATIBILITY | |
| PC Resolution (max): | 1920x1080 |
| Mac® Resolution (max): | 1920x1080 |
| PC Operating System: | Windows 7/8.1/10/11 certified; macOS tested |
| Mac® Resolution (min): | 1920x1080 |
| CONNECTOR | |
| VGA: | 1 |
| USB 2.0 Type A: | 2 |
| USB 2.0 Type B: | 1 |
| 3.5mm Audio In: | 1 |
| 3.5mm Audio Out: | 1 |
| HDMI 1.4: | 1 |
| DVI-D: | 1 |
| Power in: | 3-pin Socket (IEC C14 / CEE22) |
| AUDIO | |
| Internal Speakers: | 2Watts x2 |
| POWER | |
| Eco Mode (Conserve): | 11.5W |
| Eco Mode (optimized): | 13.5W |
| Consumption (typical): | 15.5W |
| Consumption (max): | 16.5W |
| Voltage: | AC 100-240V |
| Stand-by: | 0.5W |
| Power Supply: | Internal Power Supply |
| ADDITIONAL HARDWARE | |
| Kensington Lock Slot: | 1 |
| Cable Organization: | Yes |
| CONTROLS | |
| Physical Controls: | 1, 2, Up, Down, Power |
| On Screen Display: | Auto Image Adjust, Contrast/Brightness, Input Select, Audio Adjust, Color Adjust, Information, Manual Image Adjust, Setup Menu, Memory Recall |
| OPERATING CONDITIONS | |
| Temperature: | 32°F to 104°F (0°C to 40°C) |
| Humidity (non-condensing): | 20% to 90% |
| WALL MOUNT | |
| VESA Compatible: | 100 x 100 mm |
| INPUT SIGNAL | |
| Frequency Horizontal: | 24 ~ 82KHz |
| Frequency Vertical: | 50 ~ 75Hz |
| VIDEO INPUT | |
| Digital Sync: | TMDS - DVI-D, TMDS - HDMI (v1.4) |
| Analog Sync: | Separate/Composite/SOG - RGB Analog |
| ERGONOMICS | |
| Tilt (Forward/Back): | 20º / 40º |
| WEIGHT (IMPERIAL) | |
| Net (lbs): | 11.5 |
| Net Without Stand (lbs): | 10.3 |
| Gross (lbs): | 15.4 |
| WEIGHT (METRIC) | |
| Net (kg): | 5.2 |
| Net Without Stand (kg): | 4.7 |
| Gross (kg): | 7 |
| DIMENSIONS (IMPERIAL) (WXHXD) | |
| Packaging (in.): | 25.4 x 16.6 x 6.5 |
| Physical (in.): | 22.5 x 13.7 x 4 |
| Physical Without Stand (in.): | 22.5 x 13.7 x 2.4 |
| DIMENSIONS (METRIC) (WXHXD) | |
| Packaging (mm): | 645 x 422 x 166 |
| Physical (mm): | 571 x 348 x 101 |
| Physical Without Stand (mm): | 571 x 348 x 61 |
| GENERAL | |
| Regulations: | cTUVus, FCC-B, ICES003, Energy Star, EPEAT, CEC, MX-CoC, Mexico Energy, CE, CE EMC, CB, RoHS, ErP, REACH, WEEE, EAC, UkrSEPRO, RCM, GEMS, VCCI, PSE, BIS, CCC, China RoHS, China Energy Label, CECP |
| PACKAGE CONTENTS: | TD2423 x1, 3-pin Plug (IEC C13 / CEE22) x1, HDMI Cable (v1.4; Male-Male) x1, USB A/B Cable (v2.0; Male-Male) x1, Audio Cable (Male-Male) x1, Quick Start Guide x1 |
| Recycle/Disposal: | Please dispose of in accordance with local, state or federal laws. |
| Warranty: | *Warranty offered may differ from market to market |
| Power Management: | Energy Star standards, EPEAT |
