About this item:

12TH GEN CORE, STABLE PERFORMANCE - The PRO Z690-P DDR4 is a compact motherboard for the Intel Z690 chipset (LGA 1700, 12th Gen Core ready); The VRM features MSI Core Boost technology for improved stability & peformance
SMART COOLING - Frozr AI Cooling automatically adjusts system fan speeds based on CPU & GPU temperatures, while the VRM includes an extended heatsink design for enhanced passive cooling
MULTI-GPU SLOTS, HIGH RAM SPEEDS – The primary PCIe 5.0 x16 slot (with steel frame) supports AMD CrossFire technology (via tertiary PCIe 3.0 x16 slot); quad DDR4 DIMMs with Memory Boost architecture enable faster SDRAM for overclocking (5000+MHz/OC)
Dual M.2 Gen4 CONNECTORS - Storage includes 2 x M.2 Gen4 x4 64Gb/s slots (Intel Optane supported) for hyper-fast SSD access when launching system-demanding programs or large files
WELL CONNECTED - Features USB 3.2 Gen 2x2 Type-C for fast file transfers (20Gb/s), 4K/30Hz HDMI display interface, 2.5G LAN, and 7.1 HD Audio with Audio Boost

From the manufacturer:

MSI Business & Productivity

MSI Business & Productivity specializes in home & commercial office computing hardware with a design emphasis on productivity and user comfort.

For business professionals searching for elegant, world class solutions engineered with cutting edge components, premium reliability and refined aesthetics, MSI Business & Productivity offers a broad array of innovative products to ensure a competitive working environment.

PRO Z690-P DDR4

Business Elegance

For professionals looking for value-centric 12th Gen Intel Core performance with high-bandwidth PCIe 5.0 x16 graphics card architecture, improved DDR4 memory, and M.2 Gen4 storage options, the MSI PRO Z690-P DDR epitomizes business elegance.

Supports Intel Core 12th Gen Processors (LGA 1700)
4 x DDR4 DIMMs, Memory Boost (5000MHz OC)
2 x M.2 Gen4 Slots
1 x PCI-e 5.0 x16 (128GB/s), 1 x PCI-e 3.0 x16 Graphic Card Slots
2.5G LAN
USB 3.2 Gen 2x2 Type-C (20Gbps)

Z690 Chipset, Smart Cooling, DDR4 Memory Boost

MSI PRO Z690-P DDR4 intel core support

Supports Intel Core 12th Gen Processors

The PRO Z690-P DDR4 motherboard supports 12th Gen Intel Core processors.

Form Factor: ATX
Socket Type: LGA 1700
Chipset: Intel Z690

MSI PRO Z690-P DDR4 smart cooling

Smart Cooling

VRM Cooling: Features an extended heatsink for improved thermal dissipation.

Frozr AI Cooling: Automatically adjusts system cooling based on CPU & GPU temperatures.

A 6-layer server-grade PCB with 2oz of thickened copper improves performance & system stability.

MSI PRO Z690-P DDR4 dual channel

4 x DDR4 Dual Channel (5000 MHz Overclocked*)

Memory Boost: A fully-isolated circuit delivers pure DDR4 data signals for optimal gaming and overclocking performance.

XMP profiles in MSI BIOS are MSI OC LAB optimized and can be easily enabled with auto power settings for improved memory speed and stability.

*1DPC 1R Max. overclocking frequency 5000 MHz, supports Intel XMP.

PCI-e 5.0 x16 Slot, Cutting-Edge Storage Performance, 2.5G LAN Connectivity

MSI PRO Z690-P DDR4 pci

Fortified PCI-e 5.0 x16

MSI PCI Express Steel Armor slots are secured to the motherboard with extra solder points* to support the weight of heavy graphics cards and shields the point of contact from electromagnetic interference:

1 x PCI-e 5.0 x16 slot (with Steel Armor)
1 x PCI-e 3.0 x16 slot
3 x PCI-e 3.0 x1 slots

*All-new MSI Surface Mount Technology (SMT) solder welding improves signal clarity.

MSI PRO Z690-P DDR4 gen4 connectors

Gen4 M.2 Connectors

The PRO Z690-P DDR4 motherboard features MSI's latest M.2 slots (Intel Optane supported):

2 x Gen4 x4 64Gb/s slots

*M.2 specifications may vary depending on the CPU installed.

MSI PRO Z690-P DDR4 connectivity

2.5G LAN Connectivity

2.5G LAN: A 2.5Gbps LAN controller delivers a premium network experience.

USB 3.2 Gen 2x2 Type-C: Enables ultra-fast 20Gbps data transfer rates between devices.

HD Audio: 7.1-Channel High Definition Audio with Audio Boost.

Technical Details:

Brand

‎MSI

Manufacturer

‎MSI, Micro-Star INT'L CO., LTD. No.69, Lide St., Zhonghe Dist., New Taipei City 235, Taiwan

Model

‎PROZ690-PDDR4

Model Year

‎2021

Product Dimensions

‎30.5 x 24.4 x 6 cm; 240.4 g

Item model number

‎PROZ690-PDDR4

RAM Size

‎128 GB

Memory Storage Capacity

‎128 GB

Memory Slots Available

‎4

Flash Memory Installed Size

‎128 GB

Ram Memory Technology

‎DDR4

Computer Memory Type

‎DDR4 SDRAM

Processor Type

‎Pentium

Processor Socket

‎LGA 1700

Compatible Processor Types

‎12th Gen Intel Core

Hardware Interface

‎USB, USB Type C

Graphics Card Interface

‎PCI-Express x16

Compatible Devices

‎Personal Computer

Chipset Type

‎Intel Z690

Mounting Hardware

‎Motherboard, Sata Cable, Manual, I/O Shield, CD, M.2 Screws/Standoff Sets, Registration Card, Thank you card

Number of items

‎1

Voltage

‎1 Volts

Batteries Included

‎No

Batteries Required

‎No

Total USB ports

‎11

Form Factor

‎atx

Manufacturer

‎MSI

Country of Origin

‎China

Item Weight

‎240 g

Warranty

3 Years
