Specifications

Chipset	AMDB650
CPU SUPPORT	Supports AMD Ryzen 7000 Series Desktop Processors
CPU SUPPORT	Socket AM5
Memory	4x DDR5, Maximum Memory Capacity 128GB
Memory	Memory Support DDR5 6600+(OC)/6400(OC)/6200(OC)/6000(OC)/5800(OC)/5600(OC)/5400(OC)/5200(OC)/5000(OC)/4800(JEDEC) MHz
Onboard Graphics	1x HDMI
	1x DisplayPort Support HDMITM 2.1 with HDR
	maximum resolution of 4K 60Hz Support DP 1.4 maximum resolution of 8K 60Hz
EXPANSION SLOT	2x PCI-E x16 slot
	Support x16/ x4
	1x PCI-E x1 slot
	PCI_E1 PCIe 4.0 supports up to x16 (From CPU)
	PCI_E2 PCIe 4.0 supports up to x4 (From Chipset)
	PCI_E3 PCIe 3.0 supports up to x1 (From Chipset)
Storage	3x M.2 slot M.2_1 (From CPU) supports up to PCIe 4.0 x4 ,
	supports 2280/2260 devices M.2_2 (From CPU)
	supports up to PCIe 4.0 x4
	supports 2280/2260 devices M.2_3 (From Chipset) supports up to PCIe 4.0 x4
	supports 2280/2260 devices 6x SATA 6G port
RAID	Supports RAID 0, RAID 1, and RAID 10 for SATA storage devices
RAID	Supports RAID 0 and RAID 1 for M.2 NVMe storage devices
USB	2x USB 2.0 (Rear)
	4x USB 2.0 (Front)
	4x USB 3.2 Gen1 Type A (Rear)
	2x USB 3.2 Gen1 Type A (Front) 3x USB 3.2 Gen2 Type A (Rear)
	1x USB 3.2 Gen2 Type C (Front)
	1x USB 3.2 Gen2x2 Type C (Rear)
LAN	Realtek RTL8125B 2.5Gbps LAN
WIRELESS / BLUETOOTH	AMD Wi-Fi 6E
	The Wireless module is pre-installed in the M.2 (Key-E) slot
	Supports MU-MIMO TX/RX
	Supports 20MHz,
	40MHz,
	80MHz,160MHz bandwidth in 2.4GHz/ 5GHz or 6GHz bands Supports 802.11 a/ b/ g/ n/ ac/ ax Supports BluetoothÃ 5.2
Audio	Realtek ALC4080 Codec 7.1-Channel High Performance Audio Supports S/PDIF output Supports up to 32-Bit/384 kHz playback on front panel
Internal I/O	1x Power Connector(ATX_PWR)
	2x Power Connector(CPU_PWR)
	1x CPU Fan
	1x Pump Fan
	6x System Fan
	2x Front Panel (JFP)
	1x Chassis Intrusion (JCI)
	1x Front Audio (JAUD)
	1x Tuning Controller connector(JDASH)
	2x Addressable V2 RGB LED connector (JARGB_V2)
	2x RGB LED connector(JRGB)
	1x TPM pin header(Support TPM 2.0)
	4x USB 2.0
	2x USB 3.2 Gen1 Type A
	1x USB 3.2 Gen2 Type C
LED FEATURE	4x EZ Debug LED
OPERATING SYSTEM	Support for WindowsÃ 11 64-bit, WindowsÃ 10 64-bit
Warranty	3 Years
PCB Dimension	ATX 243.84mmx304.8mm

*Note: The actual colors may be different from the color displayed here. Features, Price and Specifications are subject to change without notice.
