About this item

Supports 7th and 6th Generation Intel Core i5/i3/Pentium /Celeron, Processors
Supports DDR4 2400/2133 MHz
1 PCIe 3.0 x16, 12 PCIe 3.0 x1
Graphics Output: HDMI
7.1 CH HD Audio (Realtek ALC897 Audio Codec)

Technical Details

Platform	INTEL
Socket	LGA1151
CPU Type	7th Gen,6th Gen, Pentium
Chipset	Q270
Memory Speed	up to 2400
Max Memory Support	32 GB
Supported Memory Type	DDR4
Channel Supported	Dual Channel
Memory Feature	Supports ECC UDIMM memory modules (operate in non-ECC mode) Supports Intel® Extreme Memory Profile (XMP) 2.0 15μ Gold Contact in DIMM Slots
Expansion Slots	- 1 x PCI Express 3.0 x16 Slot (PCIE2: x16 mode) - 12 x PCI Express 3.0 x1 Slots
Back Panel I/O Ports	- 1 x PS/2 Mouse Port - 1 x PS/2 Keyboard Port - 1 x HDMI Port - 4 x USB 2.0 Ports (Supports ESD Protection) - 2 x USB 3.2 Gen1 Ports (Supports ESD Protection) - 1 x RJ-45 LAN Port with LED (ACT/LINK LED and SPEED LED) - HD Audio Jacks: Line in / Front Speaker / Microphone
Internal I/O Connector	- 1 x System Panel Header - 1 x TPM Header - 1 x COM Port Header - 1 x Chassis Intrusion and Speaker Header - 1 x CPU Fan Connector (4-pin) - 2 x Chassis Fan Connectors (4-pin) (Smart Fan Speed Control) - 1 x 24 pin ATX Power Connector - 1 x 8 pin 12V Power Connector - 2 x PCIe Power Connectors - 1 x SATA Power Connector - 1 x Front Panel Audio Connector - 1 x USB 2.0 Header (Supports 2 USB 2.0 ports) (Supports ESD Protection) - 1 x USB 3.2 Gen1 Header (Supports 2 USB 3.2 Gen1 ports) (Supports ESD Protection) - 1 x Power Button - 1 x Reset Button
Form Factor	ATX
Warranty	3 Years
