GIGABYTE GA-H310M-DS2 INTEL LGA1151 MOTHERBOARD

Name: GIGABYTE GA-H310M-DS2 INTEL LGA1151 MOTHERBOARD
Brand: Gigabyte
Price: 6200.0 INR
Availability: OutOfStock

₹ 6,200 ₹ 8,000

Discount: ₹ 1,800 (23%)

14 people are viewing this right now

Hurry Up! Only Few Left in Stock!

Notify Me

Add wishlist Delete wishlist Add compare Delete compare

Share

Estimated Dispatch: 24 - 48hrs

Availability: In Stock Unavailable

SKU: 102709

Vendor: gigabyte

Model Number: H310M DS2

Guaranteed safe & Secure checkout

Description
Shipping & Return

Specifications

Supports 9th and 8th Gen IntelÃ CoreÃ´ Processors
Dual Channel Non-ECC Unbuffered DDR4
8-Channel HD Audio with High Quality Audio Capacitors
GIGABYTE Exclusive 8118 Gaming LAN with Bandwidth Management
CEC 2019 Ready, Save Power With a Simple Click
Smart Fan 5 features Multiple Temperature Sensors and Hybrid Fan Headers with FAN STOP
All new GIGABYTEÃ´ APP Center, simple and easy use
Anti-Sulfur Resistors Design

Specifications

CPU

1. Support for 9th and 8th Generation IntelÃCoreÃ´ i9 processors/IntelÃCoreÃ´ i7 processors/IntelÃCoreÃ´ i5 processors/IntelÃCoreÃ´ i3 processors/IntelÃPentiumÃprocessors/IntelÃCeleronÃprocessors in the LGA1151 package

2. L3 cache varies with CPU

(Please refer "CPU Support List" for more information.)

Chipset

1. IntelÃH310 Express Chipset

Memory

1. 2 x DDR4 DIMM sockets supporting up to 32 GB of system memory

2. Dual channel memory architecture

3. Support for DDR4 2666/2400/2133 MHz memory modules

4. Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules (operate in non-ECC mode)

5. Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules

6. Support for Extreme Memory Profile (XMP) memory modules

* To support 2666 MHz or XMP memory, you must install an 8thGeneration IntelÃCoreÃ´ i7/i5 processor.

(Please refer "Memory Support List" for more information.)

Onboard Graphics

Integrated Graphics Processor-IntelÃHD Graphics support:

1. 1 x D-Sub port, supporting a maximum resolution of 1920x1200@60 Hz

Maximum shared memory of 1 GB

Audio

1. RealtekÃALC887 codec

2. High Definition Audio

3. 2/4/5.1/7.1-channel

4. Support for S/PDIF Out

* To configure 7.1-channel audio, you have to use an HD front panel audio module and enable the multi-channel audio feature through the audio driver.

LAN

1. RealtekÃGbE LAN chip (10/100/1000 Mbit)

Expansion Slots

1. 1 x PCI Express x16 slot, running at x16

(The PCIEX16 slot conforms to PCI Express 3.0 standard.)

2. 2 x PCI Express x1 slots

(The PCI Express x1 slots conform to PCI Express 2.0 standard.)

Storage Interface

Chipset:

1. 4 x SATA 6Gb/s connectors

USB

Chipset:

1. 4 x USB 3.1 Gen 1 ports (2 ports on the back panel, 2 ports available through the internal USB header)

2. 6 x USB 2.0/1.1 ports (4 ports on the back panel, 2 ports available through the internal USB header)

Internal I/O Connectors

1. 1 x 24-pin ATX main power connector

2. 1 x 4-pin ATX 12V power connector

3. 4 x SATA 6Gb/s connectors

4. 1 x CPU fan header

5. 1 x system fan header

6. 1 x front panel header

7. 1 x front panel audio header

8. 1 x USB 3.1 Gen 1 header

9. 1 x USB 2.0/1.1 header

10. 1 x Trusted Platform Module (TPM) header (2x6 pin, for the GC-TPM2.0_S module only)

11. 1 x Clear CMOS jumper

Back Panel Connectors

1. 1 x PS/2 keyboard/mouse port

2. 1 x parallel port

3. 1 x serial port

4. 1 x D-Sub port

5. 2 x USB 3.1 Gen 1 ports

6. 4 x USB 2.0/1.1 ports

7. 1 x RJ-45 port

8. 3 x audio jacks

I/O Controller

1. iTEÃI/O Controller Chip

H/W Monitoring

1. Voltage detection

2. Temperature detection

3. Fan speed detection

4. Overheating warning

5. Fan fail warning

6. Fan speed control

* Whether the fan speed control function is supported will depend on the cooler you install.

BIOS

1. 1 x 128 Mbit flash

2. Use of licensed AMI UEFI BIOS

3. PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0

Unique Features

1. Support for APP Center

* Available applications in APP Center may vary by motherboard model. Supported functions of each application may also vary depending on motherboard specifications.

3D OSD

@BIOS

AutoGreen

Cloud Station

EasyTune

Fast Boot

Game Boost

ON/OFF Charge

Platform Power Management

Smart Backup

Smart Keyboard

Smart Survey

Smart TimeLock

Smart HUD

System Information Viewer

USB Blocker

V-Tuner

2. Support for Q-Flash

3. Support for Xpress Install

Bundled Software

1. NortonÃInternet Security (OEM version)

2. RealtekÃ8118 Gaming LAN Bandwidth Control Utility

Operating System

1. Support for Windows 10 64-bit

Form Factor

1. Micro ATX Form Factor; 22.6cm x 17.4cm
