1x HDMI™ (Support HDMI™ 1.4 with HDR, maximum resolution of 4K 30Hz)
Slot
1x PCI-E x16 slot, 1x PCI-E x1 slot
PCI_E1 Gen
PCIe 4.0 supports up to x16 (From CPU)
PCI_E2 Gen
PCIe 3.0 supports up to x1 (From Chipset)
Audio
Realtek® ALC897 Codec, 7.1-Channel High Definition Audio
Storage
1x M.2 (supports up to PCIe 3.0 x4), 2x SATA 6G
USB
4x USB 2.0 (Rear), 4x USB 2.0 (Front), 2x USB 5Gbps Type A (Rear), 2x USB 5Gbps Type A (Front)
LAN
Realtek® RTL8111H Gigabit LAN
Internal IO
1x Power Connector (ATX_PWR), 1x Power Connector (CPU_PWR), 1x CPU Fan, 1x System Fan, 2x Front Panel (JFP), 1x Chassis Intrusion (JCI), 1x Front Audio (JAUD), 1x Com Port (JCOM), 1x TPM pin header (Support TPM 2.0), 4x USB 2.0 ports
Wireless LAN & Bluetooth
Wi-Fi 6E, Bluetooth® 5.3 (FIPS, FISMA)
LED Feature
4x EZ Debug LED
Back Panel Ports
HDMI™, USB 3.2 Gen 1 5Gbps (Type-A), USB 2.0, LAN port, Audio Connectors
Operating System
Support for Windows® 11 64-bit, Windows® 10 64-bit
PCB Info
mATX, 200mm x 236.16mm
