Asus Tuf Gaming X670-E Plus Wifi DDR5 AMD AM5 Motherboard

Name: Asus Tuf Gaming X670-E Plus Wifi DDR5 AMD AM5 Motherboard
Brand: Asus
SKU: 1082966
Price: 33500.0 INR
Availability: OutOfStock

Rs. 33,500.00 Rs. 55,000.00

Discount: Rs. 21,500.00 (40%)

16 people are viewing this right now

Hurry Up! Only 0 Left in Stock!

Out of stock

Add wishlist Delete wishlist Add compare Delete compare

Share

Estimated Delivery: Jul 10 - Jul 14

Availability: In Stock Unavailable

SKU: 1082966

Vendor: Asus

Guaranteed safe & Secure checkout

Description
Shipping & Return

CPU	AMD Socket AM5 for AMD Ryzen 7000 Series Desktop Processors
Chipset	AMD X670
Memory	4 x DIMM, Max. 128GB, DDR5 6400+(OC)/ 6200(OC)/ 6000(OC)/ 5800(OC)/ 5600(OC)/ 5400(OC)/ 5200/ 5000/ 4800 ECC & Non-ECC, Un-buffered Memory
	Dual Channel Memory Architecture
	Supports AMD EXTended Profiles for Overclocking (EXPO)
	OptiMem II
	Supported memory types, data rate(Speed), and number of DRAM module vary depending on the CPU and memory configuration.
	Non-ECC, Un-buffered DDR5 Memroy supports On-Die ECC function.
	1 x DisplayPort
Graphics	1 x HDMI port
	Graphics specifications may vary between CPU types.
	Supports max. 8K@60Hz as specified in DisplayPort 1.4.
	Supports 4K@60Hz as specified in HDMI 2.1.
Expansion Slots	AMD Ryzenô 7000 Series Desktop Processors
	1 x PCIe 5.0 x16 slot
	AMD X670 Chipset
	1 x PCIe 4.0 x16 slot (supports x4 mode)
	1 x PCIe 4.0 x4 slots
Storage	Total supports 4 x M.2 slots and 4 x SATA 6Gb/s ports
	AMD Ryzenô 7000 Series Desktop Processors
	M.2_1 slot (Key M), type 2242/2260/2280 (supports PCIe 5.0 x4 mode)
	M.2_3 slot (Key M), type 2242/2260/2280 (supports PCIe 4.0 x4 mode)
	AMD X670 Chipset
	M.2_2 slot (Key M), type 2242/2260/2280/22110 (supports PCIe 3.0 x4 & SATA modes)**
	M.2_4 slot (Key M), type 2242/2260/2280 (supports PCIe 4.0 x4 mode)
	4 x SATA 6Gb/s ports
	AMD RAID Xpert Technology supports both NVMe RAID 0/1/10 and SATA RAID 0/1/10.
	M.2_2 slot shares bandwidth with SATA6G_1&2. When M.2_2 runs at PCIe x4 mode, SATA6G_1&2 will be disabled.
Ethernet	1 x Realtek 2.5Gb Ethernet
Ethernet	TUF LANGuard
Wireless & Bluetooth	Wi-Fi 6E
	2x2 Wi-Fi 6E (802.11 a/b/g/n/ac/ax)
	Supports 2.4/5/6GHz frequency band
	Bluetooth v5.2
	WiFi 6E 6GHz regulatory may vary between countries.
USB	Rear USB (Total 10 ports)
	1 x USB 3.2 Gen 2x2 port (1 x USB Type-CÆ)
	4 x USB 3.2 Gen 2 ports (3 x Type-A + 1 x USB Type-CÆ)
	5 x USB 3.2 Gen 1 ports (5 x Type-A)
	Front USB (Total 9 ports)
	1 x USB 3.2 Gen 2 connector (supports USB Type-CÆ)
	1 x USB 3.2 Gen 1 header supports additional 2 USB 3.2 Gen 1 ports
	3 x USB 2.0 headers support additional 6 USB 2.0 ports
Audio	"Realtek S1220A 7.1 Surround Sound High Definition Audio CODEC
	- Impedance sense for front and rear headphone outputs
	- Internal audio Amplifier to enhance the highest quality sound for headphone and speakers
	- Supports: Jack-detection, Multi-streaming, Front Panel Jack-retasking
	- High quality 120 dB SNR stereo playback output and 113 dB SNR recording input (Line-in)
	- Supports up to 32-Bit/192 kHz playback
	Audio Features
	- Audio shielding
	- Premium audio capacitors
	- Dedicated audio PCB layers
	- Audio cover
	- Unique de-pop circuit
	Due to limitations in HDA bandwidth, 32-Bit/192 kHz is not supported for 7.1 Surround Sound audio.
Back Panel I/O Ports	1 x USB 3.2 Gen 2x2 port (1 x USB Type-CÆ)
	4 x USB 3.2 Gen 2 ports (3 x Type-A, 1 x USB Type-CÆ)
	5 x USB 3.2 Gen 1 ports (5 x Type-A)
	1 x DisplayPort
	1 x HDMIÆ port
	1 x Wi-Fi Module
	1 x Realtek 2.5Gb Ethernet port
	5 x Audio jacks
	1 x BIOS FlashBackô button
Internal I/O Connectors	Fan and Cooling related
	1 x 4-pin CPU Fan header
	1 x 4-pin CPU OPT Fan header
	1 x 4-pin AIO Pump header
	4 x 4-pin Chassis Fan headers
	1 x W_PUMP+ header(s)
	Power related
	1 x 24-pin Main Power connector
	2 x 8-pin +12V Power connectors
	Storage related
	4 x M.2 slots (Key M)
	4 x SATA 6Gb/s ports
	USB
	1 x USB 3.2 Gen 2 connector (supports USB Type-CÆ )
	1 x USB 3.2 Gen 1 header supports additional 2 USB 3.2 Gen 1 ports
	3 x USB 2.0 headers support additional 6 USB 2.0 ports
	Miscellaneous
	3 x Addressable Gen 2 headers
	1 x AURA RGB header
	1 x Clear CMOS header
	1 x COM Port header
	1 x Front Panel Audio header (AAFP)
	1 x 20-3 pin System Panel header with Chassis intrude function
	1 x Thermal Sensor header
	1 x Thunderboltô header
Special Features	TUF PROTECTION
	- DIGI+ VRM (- Digital power design with DrMOS)
	- ESD Guards
	- LANGuard
	- Overvoltage Protection
	- Safeslot
	- Stainless-Steel Back I/O
	ASUS Q-Design
	- M.2 Q-Latch
	- Q-DIMM
	- Q-LED (CPU [red], DRAM [yellow], VGA [white], Boot Device [yellow green])
	- Q-Slot
	ASUS Thermal Solution
	- M.2 heatsink
	- VRM heatsink design
	ASUS EZ DIY
	- BIOS FlashBackô button
	- BIOS FlashBackô LED
	- Clear CMOS header
	- ProCool
	- Pre-mounted I/O shield
	- SafeSlot
	- SafeDIMM
	AURA Sync
	- AURA RGB header
	- Addressable Gen 2 headers
Software Features	ASUS Exclusive Software
	Armoury Crate
	- AURA Sync
	- Fan Xpert 4 (with AI Cooling II)
	- Power Saving
	- Two-Way AI Noise Cancellation
	AI Suite 3
	- Easy Optimization
	- TPU
	- DIGI+ VRM
	- Turbo app
	- PC Cleaner
	TUF GAMING CPU-Z
	DTS Audio Processing
	MyAsus
	Norton Anti-virus software (Free Trial version)
	WinRAR
	UEFI BIOS
	ASUS EZ DIY
	- ASUS CrashFree BIOS 3
	- ASUS EZ Flash 3
	- ASUS UEFI BIOS EZ Mode
	FlexKey
BIOS	256 Mb Flash ROM, UEFI AMI BIOS
Manageability	WOL by PME, PXE
Accessories	Cables
	2 x SATA 6Gb/s cables
	Miscellaneous
	1 x ASUS Wi-Fi moving antenna
	2 x Rubber packages for M.2
	2 x Screw packages for M.2 SSD
	Documentation
	1 x TUF certification card
	1 x User guide
Operating System	WindowsÆ 11 64-bit, WindowsÆ 10 64-bit
Form Factor	ATX Form Factor
Form Factor	12 inch x 9.6 inch ( 30.5 cm x 24.4 cm )
Warranty	3 Years

*Note: The actual colors may be different from the color displayed here. Features, Price and Specifications are subject to change without notice.
