Description
About the item
- Plug and play – No software or drivers required
- Power delivery 3.0 provides up to 100W of power passthrough
- Reversible and symmetrical USB-C® connector
- DisplayPort™ Alt Mode for HDMI™
- Supports up to 4K resolution
- Reliable network connectivity via the Gigabit Ethernet port
Specifications
Specification | Details |
---|---|
Hardware | |
Audio Supported | Yes |
Host Connector | USB-C® |
Ports | 1 – USB-C® PD for upstream charging |
1 – 4K HDMI™ Output | |
1 – Gigabit Ethernet | |
Power Source | Bus-Powered, Self-powered |
USB Pass-Through | N/A |
Video Output | HDMI™ |
Warranty | 2 Year Limited |
Performance | |
Audio Channel | 2.1 via HDMI™ |
Displays Supported | 1 |
Max Data Transfer Rate | N/A |
Max Display Refresh Rate | 30 Hz |
Max Display Resolution | 3840 x 2160 |
Power | |
PD Input Current | Up to 20V |
PD Input Voltage | Up to 5A |
PD Output Current | Up to 20A |
PD Output Voltage | Up to 4.5A |
Power Consumption | ≤ 350 mA |
Power Delivery | Up to 100W via USB-C® |
Physical Specifications | |
Cable Length | 7.87 in. (20 cm) |
Color | White |
Enclosure Type | ABS Plastic |
Operating Humidity | < 85% non-condensing |
Operating Temperature | 32 to 118°F (0 to 47°C) |
Product Depth | 0.55 in. (14 mm) |
Product Height | 1.96 in. (50 mm) |
Product Weight | 1.83 oz (52 g) |
Product Width | 3.14 in. (80 mm) |
Storage Humidity | < 85% non-condensing |
Storage Temperature | 14 to 140°F (-10 to 65°C) |
Package Contents | |
1 - JCA351 USB-C® to 4K HDMI™ Ethernet Adapter | |
1 - Quick Installation Guide (QIG) |
