| Specification | Details |
|---|---|
| Hardware | |
| Audio Supported | N/A |
| Host Connector | 1 - USB-C® Male |
| Ports | 1 – VGA |
| Power Source | Bus-powered |
| USB Pass-Through | N/A |
| Video Output | 1 - VGA Female |
| Warranty | 2 Years Limited |
| Performance | |
| Audio Channel | N/A |
| Displays Supported | 1 |
| Max Display Refresh Rate | 60 Hz |
| Max Display Resolution | 1920 x 1200 |
| Wide Screen Supported | Yes |
| Power | |
| Power Consumption | ≤150 mA |
| Power Delivery | N/A |
| Physical Specifications | |
| Cable Length | 5.71 in (145 mm) |
| Color | Champagne Metallic |
| Enclosure Type | Aluminum |
| Operating Humidity | < 85% non-condensing |
| Operating Temperature | 32 to 118°F (0 to 48°C) |
| Product Depth | 0.56 in (14.4 mm) |
| Product Height | 2.67 in (68 mm) |
| Product Weight | 1.00 oz (28.4 g) |
| Product Width | 0.92 in (23.4 mm) |
| Storage Humidity | < 85% non-condensing |
| Storage Temperature | 14 to 149°F (-10 to 65°C) |
| Package Contents | |
| 1 x JCA111 USB-C® to VGA Adapter | |
| 1 x Quick Installation Guide (QIG) |
